Pink 70 SHA Rubber Diaphragm Seals Peroxide Cured Low Compression Set
Pink 70 SHA Rubber Diaphragm Seals Peroxide Cured Low Compression Set
Pink 70 SHA Rubber Diaphragm Seals Peroxide Cured Low Compression Set
Pink 70 SHA Rubber Diaphragm Seals Peroxide Cured Low Compression Set
Pink 70 SHA Rubber Diaphragm Seals Peroxide Cured Low Compression Set
Pink 70 SHA Rubber Diaphragm Seals Peroxide Cured Low Compression Set
Pink 70 SHA Rubber Diaphragm Seals Peroxide Cured Low Compression Set
Pink 70 SHA Rubber Diaphragm Seals Peroxide Cured Low Compression Set
Pink 70 SHA Rubber Diaphragm Seals Peroxide Cured Low Compression Set
Pink 70 SHA Rubber Diaphragm Seals Peroxide Cured Low Compression Set
Specifications
Place of Origin :
Guangdong, China
Brand Name :
Splendid
Model Number :
Diaphragm
Certification :
NSF61, KTW, WRAS, IATF16949
Packaging Details :
Standard pack: bulk pack in a plastic bag and carton box
Special pack: Paper tube, pallet etc
Supply Ability :
250000 Piece/Pieces per Month
MOQ :
100 pieces
Price :
$0.08 - $3.10/pieces
Payment Terms :
L/C, T/T
Delivery Time :
4-8weeks
Hardness :
20-90 Shore-A or IRHD
Material Type :
EPDM, F.VMQ, FKM, FFKM, HNBR, NEOPRENE, NBR, SILICONE, VAMAC...
Temperature :
-60C - 450C
Name :
Rubber Diaphragm
Certificate :
SGS , NSF , KTW , WRAS , UL
Size :
As per customer's design
Description
Factory Customized Rubber Diaphragm Peroxide Cured And Low Compression Set
Product Description
Rubber products are made of rubber raw materials for the mixing machine after the mixing of rubber as raw materials, according to the characteristics of rubber products required in the mixing of the design formula, and set the required product hardness. The product is molded by rubber plate vulcanizing machine. After the product molding, the final edge treatment, the product surface treatment is smooth without burr.

Rubber diaphragm is widely used in industry, transportation and other departments, can be used as instruments, regulators and other automatic control system sensitive components. Its working temperature is generally -50 ~ +100 ℃, the working pressure is 0 ~ 2bar.

Pink 70 SHA Rubber Diaphragm Seals Peroxide Cured Low Compression Set

Products Materials

Pink 70 SHA Rubber Diaphragm Seals Peroxide Cured Low Compression Set

Materials
NR Natural Rubber High tensile strength, good ductility
SBR Styrene Butadiene Rubber Uniform quality , less foreign matter but weak mechanical strength , can be mixed with NR , widely used in tire industry , shoe soles , tape , conveyor belt , etc
BR Polybutadiene
IIR Butyl Rubber Gas is less permeable and resistant to heat, sunlight and ozone
EPDM Ethylene propylene Rubber
CR Polychloroprene Neoprene Excellent heat aging, weather resistance, ozone resistance
XNBR Carboxylated NBR / Carboxyl Butadience Acylonitrile This gelatinization is rapid sulfur addition, short scorching time, short safe storage period, compared with the general NBR, excellent wear resistance, other characteristics are similar.
NBR Nitrile Rubber ( Buna ) Resistant to alcohol, it is the most common rubber raw material for oil seal and O-ring at present
HNBR Hydrogenated Nitrile / Highly Saturated Nitrile ( HSN ) Better temperature and weather resistance than NBR, similar oil resistance to NBR, used as seals for new R-134A refrigerant system.
PU Polyurethane Rubber High hardness, high elasticity, abrasion resistance are difficult compared to other rubbers, aging resistance, ozone resistance, oil resistance is also quite good, the general PU air tightness is good
CSM Hypalon , Polyethylene Good heat resistance, weather resistance, ozone resistance, acid resistance, often used for oxidation resistant drugs (except nitric acid, sulfuric acid)
ACM ( PA ) Polyacrylate Rubber It has good resistance to petrochemical oil, high temperature and weather. It is worse than general oil adhesive. It is widely used in automotive transmission system and power system seals.
ECO Epichlorohydrin / Hydrin Good oil resistance, heat resistance and ozone resistance
VAMAC Vamac ( Ethylene / Acryllic ) AEM Petrochemical oil resistance, heat resistance, weather resistance, ozone resistance are good, compared with PA has better temperature, widely used in automotive transmission system and power system seals.
SIL Silicone Rubber Tensile strength is worse than general rubber and does not have oil resistance, heat resistance, weather resistance, ozone resistance, low temperature are excellent, suitable for high and low temperature environment, and alcohol resistance.
FSIL Fluorinated Silicone Rubber Good resistance to oil, solvent and fuel oil, good resistance to high and low temperature, used in space parts, but mostly limited to static seals, its strength and wear resistance are not good.
FPM / FKM Fluoro Carbon Rubber High TEMPERATURE RESISTANCE IS BETTER THAN SIL, CHEMICAL resistance, MOST oil AND several solvents (EXCEPT KETones, LIPids), weather resistance, ozone resistance are good, cold resistance is poor, widely used in automobile, chemical plant parts
Please contact us for professional material selection

About us

We have more than 9000 molds, with a senior R & D team and professional production machinery, you can send your product 3D drawings, we can design your own mold for you in order to later mass production. If the product you need is a specification product and we have the existing mold, we will provide you with the best quality purchase plan.

Pink 70 SHA Rubber Diaphragm Seals Peroxide Cured Low Compression Set
