Specifications
Brand Name :
AUO
Model Number :
G121EAN01.0
Certification :
ISO 9241; IEC62341; JEITA CP-3451; ANSI/AAMI ES60601-1-2; IEC 60068
Place of Origin :
Hangzhou, China
MOQ :
100
Price :
$2~$500 per piece
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
5k-20k pieces per day
Delivery Time :
3-4 weeks
Packaging Details :
CUSTOMIZED
Size (inch) :
12.1
Resolution :
1280×800
Operating Temperature :
-30 ~ 85 °C
Brightness (cd/m²) :
500
Outline Dim(mm） :
278 × 184 × 9.64 (H×V×D)
Viewing angle(RLUD) :
IPS
Description

Product Description:

Genearal Features
Brand AUO Model Number G121EAN01.0
Diagonal Size 12.1" Resolution 1280(RGB)×800, WXGA 124PPI
Active Area 261.12(W)×163.2(H) mm Outline Dim. 278 × 184 × 9.64 (H×V×D)
Luminance 500 cd/m² (Typ.) Contrast Ratio 1000 : 1 (Typ.) (TM)
Best View On Symmetry Response Time 25 (Typ.)(Tr+Td)
Viewing Angle 89/89/89/89 Operating Mode AHVA, Normally Black, Transmissive
Interface LVDS (1 ch, 6/8-bit) , 30 pins Connector Life Span 70k
Weight 480g (Max.) Power Supply 3.3V (Typ.)
Environment Operating Temperature: -30 ~ 85 °C
Storage Temperature: -30 ~ 85 °C
More details please contact us

Features:

The key features that make the AUO G121EAN01.0 suitable for these applications include:

High luminance (500 cd/m²) and contrast ratio (1000:1)

Wide viewing angles (89/89/89/89)

Fast response time (25ms)

Wide operating temperature range (-30°C to 85°C)

Compact and lightweight design

Durable LVDS interface with a 70,000 connection lifecycle


Applications:

The AUO G121EAN01.0 12.1-inch WXGA IPS display has a wide range of typical applications, including:

Industrial and Embedded Systems:

Automation equipment and control panels

Human-machine interfaces (HMIs)

Diagnostic and monitoring devices

Transportation and logistics systems

Medical Devices:

Patient monitoring equipment

Diagnostic imaging systems

Surgical equipment displays

Telemedicine and remote healthcare applications

Automotive and Transportation:

In-vehicle infotainment systems

Instrument clusters

Navigation and GPS displays

Commercial vehicle displays (trucks, buses, etc.)

Marine and Outdoor Applications:

Marine navigation and control systems

Outdoor kiosks and information displays

Weatherproof and rugged equipment displays

Portable and Mobile Devices:

Laptops, tablets, and 2-in-1 devices

Handheld terminals and mobile computers

Portable medical devices

Ruggedized mobile equipment

Digital Signage and Kiosks:

Retail and commercial signage

Wayfinding and information kiosks

Interactive displays for public spaces

Exhibition and trade show displays

Support and Services:

- Troubleshooting and diagnosis of technical issues

- Repair and replacement services for defective parts

- Firmware and software updates for improved performance

- Technical documentation and user manuals

- Technical training for technicians and installers
