rotary dryer for gasification grade wood chips drying 280 tpd
rotary dryer for gasification grade wood chips drying 280 tpd
rotary dryer for gasification grade wood chips drying 280 tpd
rotary dryer for gasification grade wood chips drying 280 tpd
rotary dryer for gasification grade wood chips drying 280 tpd
rotary dryer for gasification grade wood chips drying 280 tpd
rotary dryer for gasification grade wood chips drying 280 tpd
rotary dryer for gasification grade wood chips drying 280 tpd
Specifications
Model Number :
CE ISO
Brand Name :
Staurk
Delivery Time :
30 days
Supply Ability :
500
Place of Origin :
CHINA
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
MOQ :
1
Description

rotary dryer for gasification grade wood chips drying 280 tpd


1.Product Introduction

This heavy-duty 280 TPD Rotary Dryer is custom-engineered to pre-treat wood chips for high-efficiency biomass gasification plants. It continuously processes 280 tons of raw wood chips daily, lowering moisture content to the strict levels (typically 10%-15%) required to maximize syngas quality and maintain stable gasifier temperatures.


2.Application

  • Optimized for Gasification: Uniformly lowers moisture to prevent syngas dilution, excessive tar formation, and thermal fluctuations inside the gasifier.

  • Deep Core Drying: Features robust internal lifting flights that thoroughly cascade heavy wood chips, ensuring heat penetrates deeply to the core of each piece without scorching the surface.

  • High Industrial Durability: Built with a reinforced steel shell and wear-resistant components to reliably handle massive daily volumes in continuous 24/7 energy plant environments.


3.Working Principle

Wet wood chips are fed into the inclined rotating drum, where specialized internal plates continuously lift and shower them through a high-temperature air stream. As the drum turns, the chips advance via gravity and an induced draft, rapidly exchanging heat to evaporate internal and surface moisture. The uniformly dried, gasification-ready chips are then discharged at the outlet, while a high-efficiency cyclone collector cleanly separates the product from the humid exhaust air.


4.Technical Specifications


​Product Specs (m)

Capacity(T/H)

Main Motor Power
(kW)

Main Motor Mode1

Main Gearbox Model

Ratio

Weight (T)

1.2x10m

2.5

7.5

Y160M-R3

ZL50-16-1

13.5

1.5x12m

3.3-4.9

10

Y160L-6B3

JZQ500-111-2F

-

18.9

1.5x15m

4-6

18.5

Y200L-6

JZQ500-111-2F

21

1.8x12m

4-6

11

Y200L-6

ZQ50-1611-2

16.46

22.33

2.2x12m

7-12

18.5

Y160L-6

JZQ650-111

31.5

37.6

2.2x14m

7-12

18.5

Y160L-6

JZQ750-111

31.5

40

2.2x16m

12

30

Y225M-6

JZQ750-11

31.5

45

2.4x14m

12

30

Y250M-6

JZQ750-111

31.5

51

2.4x18m

10-13

37

Y250M-6

ZL85-13-1

27.16

54

2.4x20m

10-14

37

Y250M-6

ZL85-13-1

27.16

54.14

3x20m

25

55

Y250M-4

ZL100-16-1

41.52

78

3x25m

32-36

75

YR280M-4

ZL100-16-1

41.52

104.9
