‌‌Product Introduction‌
This automatic stainless steel rotary dryer is a high-automation intelligent drying equipment with full stainless steel structure and full-process automatic control. All parts in direct contact with materials are made of high-quality 304/316L stainless steel, with no heavy metal precipitation, no material residue. It features unattended operation, precise parameter adjustment and stable operation, fully meeting the strict standards of new energy, fine chemical, food and pharmaceutical industries. It is the core drying equipment to ensure no material pollution, ultra-low moisture and high product qualification rate in modern intelligent production lines.

‌Working Principle‌
The obliquely installed fully enclosed stainless steel multi-cylinder insulation main body is driven by a high-torque heavy-duty transmission system to rotate at a uniform low speed. The PLC intelligent control system automatically adjusts parameters such as feeding speed, drum rotating speed and hot air temperature in real time according to the online detection data of material moisture. High-moisture materials are automatically and quantitatively fed into the inner cylinder through the sealed anti-blocking feeding port. The built-in wear-resistant anti-sticking stainless steel lifting plates continuously turn and scatter the materials as the drum rotates, making them fully contact with the hot air flow. Free moisture in the materials is efficiently and evenly evaporated through the multi-stage precise constant temperature zones, and the dried finished products that meet the preset moisture standards are automatically discharged through the special anti-caking discharging end, completing the full-process automatic drying process. The all-stainless-steel material contact system will not be corroded or abraded by materials, completely avoiding hidden dangers such as material pollution, parameter deviation and unstable product quality.

‌Core Features‌
This equipment has multiple exclusive advantages of automatic stainless steel drying. The full-process intelligent automatic control system realizes unattended operation, the temperature control accuracy is ±1℃, and the product qualification rate reaches 99.5%. The full stainless steel drum has excellent anti-corrosion and anti-wear performance, and the service life is more than 2 times that of ordinary carbon steel automatic dryers. Equipped with a full set of automatic safety protection devices such as fault self-diagnosis, over-temperature alarm and emergency shutdown, it fully meets the national industrial intelligent safety production standards. It can be customized with different daily processing capacities from 5 tons to 1000 tons according to the actual material properties and intelligent production scale of users.

Technical Specifications
