50KG Rated Load Unmanned River Cleaning Boat Mounted Millimeter Wave Radar
50KG Rated Load Unmanned River Cleaning Boat Mounted Millimeter Wave Radar
50KG Rated Load Unmanned River Cleaning Boat Mounted Millimeter Wave Radar
50KG Rated Load Unmanned River Cleaning Boat Mounted Millimeter Wave Radar
Specifications
Brand Name :
ORCAUBOAT
Model Number :
SMURF
Certification :
CE
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, D/P
Supply Ability :
100 Units Per Month/month
Delivery Time :
4-6 Weeks
Packaging Details :
Sea-Worthy Packing
Hull size (length, width and height/mm) :
2930*1773*1030
Hull material :
Aluminum alloy
Hull weight :
130KG
Rated load :
50KG
Battery life :
8 hours
Charging time :
6 hours（5%-90%)
Speed of work :
1.2m/s
Maximum speed :
2.2m/s
Depth of immersion :
470mm
Maintain waters :
6.6-11.5 acres
Safety protection and dustproof design :
The whole ship is waterproof and splash-proof
Power plant :
Electric thruster
Description

SMURF Unmanned Cleaning Boat Surface Service Robot

Product Introduction:

SMURF is an unmanned cleaning boat that integrates surface garbage cleaning, intelligent inspection, and data monitoring.

Four core functions:

unmanned cleaning, daily inspection, data monitoring, and smart management

Product Highlights:

  1. PAD control: Use PAD to control the boat, which is more powerful and intuitive than mobile phone operation, and more convenient than computer.
  2. The latest generation of battery system: The unmanned ship uses the latest generation of BYD batteries + LG imported batteries, the battery life can reach 8 hours, and the power output is enhanced.
  3. Intelligent path optimization: Through intelligent algorithm calculation, the unmanned ship can intelligently plan and optimize the water cleaning path, so as to realize the efficient and safe working process.
  4. Radar Slam: The use of millimeter-wave radar SLAM to build maps can free the ship from the constraints of GPS signals, and can clean along the 0.3m water area.

50KG Rated Load Unmanned River Cleaning Boat Mounted Millimeter Wave Radar

Category item Smurf 20 Traditional cleaning Semi-automatic machiner
Maintenance area 11.5acres/person 3.2acres/person 16.4acres/person*boat
Length of work 16h/day (continuous charging) 6h/day 6h/day
Safety Driverless, 100% safe People + tools, high labor risk Manned driving, driving risk is high
Response efficiency 24h online response Working time response Working time response
Energy consumption Clean energy, charging at night, working during the day Manpower Gasoline energy, need to be purchased at the petrol station
Skill requirements Smart machine operation, easy to use, no certificate required Skilled in using tools, skilled in ferrying boats, swimming license required Skilled in mechanical boat driving, swimming license and crew certificate are required
Quality of work Machine Cleanup, quality maintain unity Affected by work status and attitude Affected by work status and attitude

50KG Rated Load Unmanned River Cleaning Boat Mounted Millimeter Wave Radar

1. Compared with the traditional artificial water surface cleaning mode, the unmanned ship water area can be cleaned up to more than 70 mu, which is more than 2.5 times the artificial cleaning area.

2.The daily working time of the unmanned ship can reach 16h/day, the manual working time is 8h/day, and the working time can be more than 2 times of manual cleaning.

3. The unmanned ship does not need manual driving, and 100% guarantees the safety of the staff.

Product parameters:

Hull size (length, width and height/mm) 2912*1773*1030
Hull material Aluminum alloy
Hull weight 140KG
Rated load 50KG
Battery life 6-8 hours
Charging time 6 hours(5%-90%)
Depth of immersion 470mm
Maintain waters 6.6-11.5 acres
Safety protection and dustproof design The whole ship is waterproof and splash-proof
Power plant Electric thruster
Speed of work 1.2m/s
Maximum speed 2.2m/s

Basic configuration:

Sequence

Names and specifications

Remark

Quantity
1

Charging cabinet

Standard

 1
2

Pad control panel

Standard

 1
3

Wireless shore-based

Optional

 1
4

Show the big screen

Optional

 1

Value-added module:

1 COD detection module 1
2 Ammonia nitrogen detection module 1
3 Blue-green algae detection module 1
4 Chlorophyll detection module 1
5 Water depth detection module 1
6 Smart wireless propaganda module 1

FAQ:

  • How many years will this boat last?

  • The design life of the whole ship is 5 years.

  • What are the maintenance costs in the later period?
  • The main maintenance costs are the propellers and batteries (replaced every two years), the replacement cost of several thousand yuan, and the cost of other consumables such as propeller blades, antennas, etc. are very low.
  • Do you have a certificate?

  • The whole ship has CE certification.

  • Can you work at night?
  • It works perfectly at night and the boat camera supports night vision.
