40 Liters Hydraulic Monoblock Valve With Joystick Control Hydraulic Distributor Valves
40 Liters Hydraulic Monoblock Valve With Joystick Control Hydraulic Distributor Valves
40 Liters Hydraulic Monoblock Valve With Joystick Control Hydraulic Distributor Valves
40 Liters Hydraulic Monoblock Valve With Joystick Control Hydraulic Distributor Valves
40 Liters Hydraulic Monoblock Valve With Joystick Control Hydraulic Distributor Valves
40 Liters Hydraulic Monoblock Valve With Joystick Control Hydraulic Distributor Valves
40 Liters Hydraulic Monoblock Valve With Joystick Control Hydraulic Distributor Valves
40 Liters Hydraulic Monoblock Valve With Joystick Control Hydraulic Distributor Valves
Specifications
Brand Name :
HANJIU
Model Number :
4P40
Certification :
CE
Place of Origin :
CHINA
MOQ :
100 Sets
Price :
Contact the seller to get a quote
Payment Terms :
L/C,T/T,Western Union,Western Union
Supply Ability :
300000 sets per year
Delivery Time :
25 - 35 work days
Packaging Details :
Carton, Box, Pallets
Item :
monoblock valve
Material :
cast iron
Apply to :
tractor vehicles
Spool :
4 spools
Max operation pressure :
250 bar
control type :
spring return
Description


Hydraulic Monoblock Valve 40 Liters with joystick control hydraulic distributor valves


type code


P40-4-200-G08--C1ST1D12-C4ST1D1-G06-G08


Code: P40 liters
Sections: 4
Relief Valve Setting Pressure:200(bar)
Intlet Port Option: G1/2
Control Method Option: Standard handle/joystick control
Spool Function: 3 Positions, double acting;
Spool Returning Way:spring return
Working Port Option: G1/2
Outlet Port Option: G1/2


Application :


Cranes, Telescopic boom fork lifts, Back-hoe Excavators and Compactors,Sanitation Vehicles



flow rate 40 liters
number of spools 2 spools+ 1 joystick
inlet section valve side inlet, with relief valve
relief valve set pressure 200bar
inlet port size G1/2
spool type 3 Positions, Double Acting
handle side arrangement standard type
spool cap side arrangement 3position, spring return,manual control,detent control,
working section arrangement standard type
work port size G1/2
outlet section type top outlet,side
outlet port size G1/2



40 Liters Hydraulic Monoblock Valve With Joystick Control Hydraulic Distributor Valves40 Liters Hydraulic Monoblock Valve With Joystick Control Hydraulic Distributor Valves

40 Liters Hydraulic Monoblock Valve With Joystick Control Hydraulic Distributor Valves


40 Liters Hydraulic Monoblock Valve With Joystick Control Hydraulic Distributor Valves

40 Liters Hydraulic Monoblock Valve With Joystick Control Hydraulic Distributor Valves


40 Liters Hydraulic Monoblock Valve With Joystick Control Hydraulic Distributor Valves

Code Number of levers Nominal flow rate
L/min		 Max. pressure
P port
bar
P40-A1-GKZ1 1 40 250
02P40-1A1A1-GKZ1 2 40 250
03P40-1A1A1A1-GKZ1 3 40 250
04P40-1A1A1A1A1-GKZ1 4 40 250
05P40-1A1A1A1A1A1-GKZ1 5 40 250
06P40-1A1A1A1A1A1A1-GKZ1 6 40 250
07P40-1A1A1A1A1A1A1A1-GKZ1 7 40 250



Different types


40 Liters Hydraulic Monoblock Valve With Joystick Control Hydraulic Distributor Valves



40 Liters Hydraulic Monoblock Valve With Joystick Control Hydraulic Distributor Valves
