Kassbohrer Rolfo car transporter trailer hydraulic motor dual shaft MRB80C/C, 25mm key shaft,2 holes oval mounting flange
Kassbohrer Rolfo car transporter trailer hydraulic motor dual shaft MRB80C/C, 25mm key shaft,2 holes oval mounting flange
Kassbohrer Rolfo car transporter trailer hydraulic motor dual shaft MRB80C/C, 25mm key shaft,2 holes oval mounting flange
Kassbohrer Rolfo car transporter trailer hydraulic motor dual shaft MRB80C/C, 25mm key shaft,2 holes oval mounting flange
Kassbohrer Rolfo car transporter trailer hydraulic motor dual shaft MRB80C/C, 25mm key shaft,2 holes oval mounting flange
Kassbohrer Rolfo car transporter trailer hydraulic motor dual shaft MRB80C/C, 25mm key shaft,2 holes oval mounting flange
Kassbohrer Rolfo car transporter trailer hydraulic motor dual shaft MRB80C/C, 25mm key shaft,2 holes oval mounting flange
Kassbohrer Rolfo car transporter trailer hydraulic motor dual shaft MRB80C/C, 25mm key shaft,2 holes oval mounting flange
Specifications
Brand Name :
Hanjiu
Model Number :
BMRYB160
Certification :
CE
Place of Origin :
China
MOQ :
50 units
Price :
Negotiable
Payment Terms :
T/T,Western Union,Paypal .
Supply Ability :
100,000 units / Year
Delivery Time :
10-15 working days
Packaging Details :
Carton packing , with a tray or wooden box if needed .
Product name :
Hydraulic Double end motors
Displacement :
80cc,100cc,125cc,160cc......400cc
Applications :
car carriers, transporters
Oil temperature :
normal-35℃-80℃
Warranty :
1 year
Material :
cast iron
Description


Kassbohrer Rolfo car transporter trailer hydraulic motor dual shaft MRB80C/C, 25mm key shaft,

2 holes oval mounting flange


BMRYB series hydraulic motors are with dual shaft and the rollers in the gear rim reduce local stress, spread the tooth load over their projected area and reduce the tangential reaction forces on the inner gear reducing friction to a minimum. This gives long operating life and better efficiency even at continuous high pressures.


Product details:

product type BMRYB motors
displacement 80cc
flange 2-φ13.5Rhomb-flange pilot φ82.5x8
shaft φ25 straight key
oil ports G1/2 manifold mount 4-M8,G1/4


Main specification

Type BMRYB BMRYB BMRYB BMRYB BMRYB BMRYB BMRYB BMRYB
80 100 125 160 200 250 315 400
Geometric displacement (cm3 /rev.) 81.5 102 127.2 154 194 243 311 394
Max. speed (rpm) cont. 750 600 475 375 310 240 190 150
int. 940 750 600 470 375 300 240 190
Max. torque (N·m) cont. 195 240 300 360 360 390 390 365
int. 220 280 340 430 440 490 535 495
peak 270 320 370 460 560 640 650 680
Max. torque (N·m)At Shaft A cont. 98 120 150 180 180 195 195 210
int. 110 140 170 215 220 245 268 248
peak 135 160 185 230 280 320 325 340
Max. torque (N·m)At Shaft B cont. 98 120 150 180 180 195 195 210
int. 110 140 170 215 220 245 268 248
peak 135 160 185 230 280 320 325 340
Max. output (kW) cont. 12.5 13 12.5 12.5 10 7 6 5
int. 15 15 14.5 14 13 9.5 9 8
Max. pressure drop (MPa) cont. 17.5 17.5 17.5 16.5 13 11 9 8.5
int. 20 20 20 20 17.5 15 13 10
peak 22.5 22.5 22.5 22.5 22.5 20 17.5 15
Max. flow (L/min) cont. 60 60 60 60 60 60 60 60
int. 75 75 75 75 75 75 75 75

Kassbohrer Rolfo car transporter trailer hydraulic motor dual shaft MRB80C/C, 25mm key shaft,2 holes oval mounting flange


Kassbohrer Rolfo car transporter trailer hydraulic motor dual shaft MRB80C/C, 25mm key shaft,2 holes oval mounting flange
Kassbohrer Rolfo car transporter trailer hydraulic motor dual shaft MRB80C/C, 25mm key shaft,2 holes oval mounting flange

Hydraulic motors are rotary actuators that convert hydraulic, or fluid energy into mechanical power. They work in tandem with a hydraulic pump, which converts mechanical power into fluid, or hydraulic power.

Hydraulic motors provide the force and supply the motion to move an external load. Hidros provide complete line of low speed, high torque hydraulic motors for agricultural, mobile and industrial applications. BMRYB series are with dual shaft and the rollers in the gear rim reduce local stress, spread the tooth load over their projected area and reduce the tangential reaction forces on the inner gear reducing friction to a minimum. This gives long operating life and better efficiency even at continuous high pressures.

Application

Conveyors;
Feeding mechanism of robots and manipulators;
Metal working machines;
Textile machines;
Food industries;
Agriculture machines;
Mining machinery etc.
