Hydraulic Orbit Motor BMM & BMSY series low speed high torque motor for slow blower
Hydraulic Orbit Motor BMM & BMSY series low speed high torque motor for slow blower
Hydraulic Orbit Motor BMM & BMSY series low speed high torque motor for slow blower
Hydraulic Orbit Motor BMM & BMSY series low speed high torque motor for slow blower
Hydraulic Orbit Motor BMM & BMSY series low speed high torque motor for slow blower
Hydraulic Orbit Motor BMM & BMSY series low speed high torque motor for slow blower
Hydraulic Orbit Motor BMM & BMSY series low speed high torque motor for slow blower
Hydraulic Orbit Motor BMM & BMSY series low speed high torque motor for slow blower
Specifications
Brand Name :
HANJIU
Model Number :
BMM, BMSY
Certification :
CE
Place of Origin :
China
MOQ :
50 Pieces
Price :
Negotiable
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,Payple
Supply Ability :
70000 pieces per year
Delivery Time :
10 - 15 work days
Packaging Details :
1 pc/ inner carton, 3 pcs/ outer carton, 27x40x14cm, transport with wooden pallet, 1500 pcs/ 20GP, 3000 pcs/ 40GP
Type :
Gerotor Hydraulic Motor
Application :
snow blower
material :
cast iron
warranty :
12 months
color :
black
delivery time :
35days
Description

Hydraulic Orbit Motor BMM & BMSY series low speed high torque motor for slow blower


Product Details:

HANJIU Hydraulic motors, BMM series motors and BMSY series motors, widely used on

the slow blower. that will bring new performance of your equipment, and cut your costs down



Main Specifications:


type BMM8 BMM12 BMM20 BMM32 BMM40 BMM50
displacement 8.2 12.9 19.9 31.6 39.8 50.3
Max speed(rpm) rated 1537 1256 814 513 452 358
Cont. 1950 1550 1000 630 500 400
int. 2450 1940 1250 800 630 500
Max Torque
(N*M)		 rated 8 13 19 31 37 33
Cont. 11 16 25 40 45 46
int. 15 23 35 57 70 88
peak 21 33 51 64 82 100
Max speed
(kw)		 rated 1.3 1.7 1.7 1.7 1.7 1.2
Cont. 1.8 2.4 2.4 2.4 2.2 1.8
int. 2.6 3.2 3.2 3.2 3.2 3.2
Max pressure
drop(MPa)		 rated 9 9 9 9 8.5 6
Cont. 10 10 10 10 9 7
int. 14 14 14 14 14 14
peak 20 20 20 16 16 16
Max flow(L/min) rated 14 18 18 18 20 20
Cont. 18 20 20 20 20 20
int. 20 25 25 25 25 25
Weight(kg) 1.9 2 2.1 2.2 2.3 2.4


Type
Max.inlet pressure
BMM8-50 Cont. 17.5
(Mpa) Int. 22.5



Type BMSY 80 BMSY 100 BMSY 125 BMSY 160 BMSY 200 BMSY 250 BMSY 315 BMSY 375
Geometric displacement (cm³/rev.) 80.6 100.8 125 157.2 200 252 314.5 370
Max. speed (rpm) 800 748 600 470 375 300 240 200
Max. torque (N*m) 190 240 310 316 400 450 560 536
Max. output (kW) 15.9 18.8 19.5 15.6 15.7 14.1 14.1 11.8
Max. pressure drop (MPa) 17.5 17.5 17.5 15 14 12.5 12 10
Weight (kg) 9.8 10 10.3 10.7 11.1 11.6 12.3 12.6


Hydraulic Orbit Motor BMM & BMSY series low speed high torque motor for slow blower

Hydraulic Orbit Motor BMM & BMSY series low speed high torque motor for slow blower

Hydraulic Orbit Motor BMM & BMSY series low speed high torque motor for slow blower

If you are looking for high quality and high performance orbital motor, HANJIU is undoubtedly your best choice. With professional technology, high quality products and perfect service, we will provide strong power for your equipment and help you stand out in the industry.
