Maintenance Danfoss Hydraulic Motor Omsw125 151f0523 Wheel Engine 32mm Shaft Side Port
Maintenance Danfoss Hydraulic Motor Omsw125 151f0523 Wheel Engine 32mm Shaft Side Port
Maintenance Danfoss Hydraulic Motor Omsw125 151f0523 Wheel Engine 32mm Shaft Side Port
Maintenance Danfoss Hydraulic Motor Omsw125 151f0523 Wheel Engine 32mm Shaft Side Port
Maintenance Danfoss Hydraulic Motor Omsw125 151f0523 Wheel Engine 32mm Shaft Side Port
Maintenance Danfoss Hydraulic Motor Omsw125 151f0523 Wheel Engine 32mm Shaft Side Port
Specifications
Brand Name :
HANJIU CHINA
Model Number :
OMSW125
Certification :
CE/ISO9001:2015
Place of Origin :
CHINA
MOQ :
50 Pieces
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, Payple
Supply Ability :
100000 pieces per year
Delivery Time :
25 - 35 work days
Packaging Details :
2pcs/32x32x17cm
Product :
Wheel engine motor
Displacement :
125ml/r
Flange :
wheel flange
Shaft :
key shaft
Max Flow :
cont.75/int.90 L/min
Max Speed :
cont.600/int.720rpm
Description

Hydraulic Maintenance Motor Danfoss Omsw125 151f0523 Wheel Engine Φ32mm Shaft Side Port

Product details:

  • Output volume (cc/rev):125,7
  • Shaft Ø (mm):32
  • Max. speed (rpm):600
  • Torque max. (Nm):375
  • Power max. (kW):18,0
  • Pressure difference (bar):210
  • Inlet pressure (bar):230
  • Volume flow max. (l/min):75
  • Motor version:with check valves
  • Connection:G 1/2"
  • Leak oil connection:G 1/4"
  • L (mm):137
  • L1 (mm):21,8
  • Danfoss reference no.:151F0523

Main Specifications:

Type BMSY
80		 BMSY
100		 BMSY
125		 BMSY
160		 BMSY
200		 BMSY
250		 BMSY
315		 BMSY
400

BMSY

475
Geometric displacement
(cm3 /rev.)		 80.6 100.8 125 157.2 200 252 314.5 394 475
Max. speed (rpm) cont. 800 748 600 470 375 300 240 185 155
int. 988 900 720 560 450 360 280 225 185
Max. torque (N·m) cont. 190 240 310 316 400 450 560 880 910
int. 240 300 370 430 466 540 658 980 990
peak 260 320 400 472 650 690 740 751 760
Max. output (kW) cont. 15.9 18.8 19.5 15.6 15.7 14.1 14.1 11 9
int. 20.1 23.5 23.2 21.2 18.3 17 18.9 12 11
Max. pressure drop (MPa) cont. 17.5 17.5 17.5 15 14 12.5 12 16 14
int. 21 21 21 21 16 16 14 19 15
peak 22.5 22.5 22.5 22.5 22.5 20 18.5 21 17.5
Max. flow (L/min) cont. 65 75 75 75 75 75 75 75 75
int. 80 90 90 90 90 90 90 90 90
Max. inlet pressure (MPa) cont. 25 25 25 25 25 25 25 25 25
int. 30 30 30 30 30 30 30 30 30
Weight (kg) 9.8 10 10.3 10.7 11.1 11.6 12.3 12.6 14.3

* Continuous pressure :Max. value of operating motor continuously.
* Intermittent pressure :Max. value of operating motor in 6 seconds per minute.
* Peak pressure:Max. value of operating motor in 0.6 second per minute.

The recessed mounting flange of a wheel motor makes it possible to fit into a wheel hub or winch drum so that the radial load acts midway between the two motor bearings. This gives the best utilisation of the bearing capacity and is a very compact solution..

Maintenance Danfoss Hydraulic Motor Omsw125 151f0523 Wheel Engine 32mm Shaft Side PortMaintenance Danfoss Hydraulic Motor Omsw125 151f0523 Wheel Engine 32mm Shaft Side PortMaintenance Danfoss Hydraulic Motor Omsw125 151f0523 Wheel Engine 32mm Shaft Side Port
