800300C8923AAAAA D9 Series Interchange White Hydraulic Motor
800300C8923AAAAA D9 Series Interchange White Hydraulic Motor
800300C8923AAAAA D9 Series Interchange White Hydraulic Motor
800300C8923AAAAA D9 Series Interchange White Hydraulic Motor
800300C8923AAAAA D9 Series Interchange White Hydraulic Motor
800300C8923AAAAA D9 Series Interchange White Hydraulic Motor
Specifications
Brand Name :
HANJIU
Model Number :
800300C8923AAAAA
Certification :
CE
Place of Origin :
China
MOQ :
100 Pieces
Price :
218 USD
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Supply Ability :
10000 pieces per year
Delivery Time :
55 work days
Packaging Details :
Box, Pallet
Item :
Orbit Hydraulic Motor
OEM # :
800300C8923AAAAA
Manufacturer :
Hanjiu
Displacement :
300 ml/r
Mounting flange :
4-hole wheel flange
Shaft type :
Spline
Description

800300C8923AAAAA White Hydraulic Motor D9 Series Interchange

This is a replacement for White Hydraulic Motor D9 series, it's not made by White.

Applications:

Construction equipment, agricultural equipment, mining equipment, forrestry equipment, associated attachments and more

Specification:

Displacement
cm3 [in
3/rev]
294 [17.9]
Max. Speed RPM cont. inter.
530 / 688
Max. Flow lpm [gpm] cont. inter.
159 [42] 204 [54]
Max. Torque Nm [lb-in] cont. inter.
870 [7700] 1017 [9000]

Overview:

The product is capable of producing torque values comparable to competitive motors, but with an industry leading breadth of displacements and shaft and porting options. In addition, the product incorporates dual tapered roller bearings, which improve load carrying capabilities. The motor is designed for use with a -drain, which reduces pressure on the shaft seal and maintains lubrication to internal drive components, maximizing motor life. The series is available with industry standard mounting flanges found throughout the global market place.

Features / Benefits:


Industry Standard Mounting Flanges that satisfy the global market place.

Dual Tapered Roller Bearings improve load carrying capability.

Nine Displacement Options provide industry leading design flexibility.

Roller Stator Design incorporates 8 lobe rotor and 9 pocket stator technology.

800300C8923AAAAA D9 Series Interchange White Hydraulic Motor

800300C8923AAAAA D9 Series Interchange White Hydraulic Motor
