Advanced Hydraulic Solutions Hydraulic Directional Valves For Agricultural Machinery
Advanced Hydraulic Solutions Hydraulic Directional Valves For Agricultural Machinery
Advanced Hydraulic Solutions Hydraulic Directional Valves For Agricultural Machinery
Advanced Hydraulic Solutions Hydraulic Directional Valves For Agricultural Machinery
Advanced Hydraulic Solutions Hydraulic Directional Valves For Agricultural Machinery
Advanced Hydraulic Solutions Hydraulic Directional Valves For Agricultural Machinery
Specifications
Brand Name :
HANJIU
Model Number :
P40
Certification :
CE
Place of Origin :
CHINA
MOQ :
30 Sets
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
300000 sets per year
Delivery Time :
10-15 work days
Packaging Details :
Carton Packing and finally with a Tray, or Wooden Box
Model No. :
P40
Warranty :
one year
Spool :
1, 2, 3, 4, 5, 6,7 ...
Flow :
40lt, 50lt, 60lt, 80lt, 100lt, 120lt, 140lt, ...
Spool function :
spring function,detent control
port size :
BSP ports
Description

advanced hydraulic solutions hydraulic directional valves for agricultural machinery new facility

Hanjiu hydraulic supply the hydraulic control valves widely used on agricultural machines

the advanced hydraulic products can bring the new performance of the machines,

it is easy to operate,long life, very suitable for your machinery.

Product details

Ambient temperature -40C...+60C
Viscosity 12 ...800 mm2/s
Fluid temperature -15C...+80C
Filtration 10 to NAS 1638
Max operating pressure 250 bar
Back pressure 50 bar
Nominal flow 40 l/min
Spool stroke 9 mm
Actuating force < 200 N
Structure 1 spool,2spools,3spools,4spools...7spools

Control type:

Advanced Hydraulic Solutions Hydraulic Directional Valves For Agricultural Machinery

Advanced Hydraulic Solutions Hydraulic Directional Valves For Agricultural Machinery

Hanjiu hydraulic has been a premier manufacturer of hydraulic distributor valves,hydraulic orbit motors,hydraulic orbitrol steering units. Directly interchangeable with DANFOSS,EATON,BADESTNOST’ brand hydraulic components

Hanjiu hydraulic offers both complete new units as well as high quality products, work with us, your business is safe;
work with us, your company sales is increasing more per year

Advanced Hydraulic Solutions Hydraulic Directional Valves For Agricultural Machinery
