Specifications
Brand Name :
HANJIU
Model Number :
BMER-3-240
Certification :
CE, ISO9001
Place of Origin :
China
MOQ :
100 Pieces
Price :
175 usd/pc
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, Payple
Supply Ability :
70000 pieces per year
Delivery Time :
45 - 55 work days
Packaging Details :
Box, carton, pallet
Product :
Low Speed, High Torque (LSHT) Motor
Model No. :
BMER-3-240
Displacement :
240cc
Flange :
4 bolt Wheel mount
Shaft :
tappered shaft
Port :
SAE ports
Rotation :
Standard
Color :
Black
Description

Wheel Motor Replacement for Exmark 1-523328 Toro 103-6988 Oregon 27-500 Parker TF0240US081AADD Stens 025-503

Quick review:

Product torqmotor, wheel drive motor
Model No. BMER-2-250-WS-T31-R
Displacement 250CC
Flange 4 bolts wheel shaft, 147.6mm
Shaft tappered shaft
Port
7/8-14 UNF
Rotation Standard
Color Black
Brand Hanjiu

Replaces part number:
For Exmark 1-523328 1523328
For Toro 103-6988 1036988
For Oregon 27-500 27500
For Parker TF0240US081AADD
For Stens 025-503 025503

Application:
Lazer Z Serial No. 102,000-370,000 52", 60" and 72" decks;
Lazer Z HP Serial No. 160,000-370,000, 44", 48" and 52" decks, Z 500's Z Master, 2004 & Newer 60" and 72" ;
Z 250's Z Master 742XX Series, 1999-2040, 52", 62" and 72" decks

Specification:

Type BMER BMER BMER BMER BMER BMER BMER BMER BMER BMER BMER
125 160 200 230 250 300 350 375 475 540 750
Geometric displacement (cm3/rev.) 118 156 196 228 257 296 345 371 462 540 745
Max. speed (rpm) cont. 360 375 330 290 290 250 220 200 160 140 100
int. 490 470 425 365 350 315 270 240 195 170 120
Max. torque (N•m) cont. 325 450 530 625 700 810 905 990 1085 980 1050
int. 380 525 600 710 790 930 1035 1140 1180 1240 1180
peak 450 590 750 870 980 1120 1285 1360 1260 1380 1370
Max. output (kW) cont. 12.0 15.0 15.5 16.0 17.5 18.0 17.5 16.5 14.5 11.5 8.0
int. 14.0 17.5 18.0 19.0 20.0 21.0 20.0 19.0 16.5 15.0 10.0
Max. pressure drop (MPa) cont. 20.5 20.5 20.5 20.5 20.5 20.5 20.5 20.5 17.5 14 10.5
int. 24 24 24 24 24 24 24 24 19 17.5 12
peak 27.6 27.6 27.6 27.6 27.6 27.6 27.6 27.6 20.5 20.5 14
Max. flow (L/min) cont. 45 60 70 70 75 80 80 75 75 75 75
int. 60 75 85 85 90 95 95 90 90 90 90
