Specifications
Brand Name :
HANJIU
Model Number :
BMS
Certification :
CE
Place of Origin :
China
MOQ :
50 Pieces
Price :
Negotiable
Payment Terms :
L/C, T/T, L/C, T/T, Western Union, Paypal
Supply Ability :
100,000 pieces per year
Delivery Time :
10-15 working days
Packaging Details :
Carton Packing, and finally with pallet or wooden box
Product :
Hydraulic Engine
Feature :
Replacement of , Eaton, M+S, Parker, etc
Displacement :
50-500 cc/rev
Weight :
9.5-14KGS
HS Code :
84122910
Color :
Black or Gray
Description

Low RPM Hydraulic Motor BMS/2000 Series φ31.75mm Straight Shaft


Characteristic Features:

1. Advanced design in disc distribution flow, which can automatically compensatein operating.


2. Shaft seal can bear high pressure of back and the motor can be used in parallel or inseries.


3. Special design in the driver-linker and prolong operation life.


4. The output shaft adopts in tapered roller bearings thatpermit high axial and radial forces. The can offers capacities of highpressure and high torque in the wide of applications.


5. Various kinds of flange, output shaft and oil port mounting dimension.

Applications:

BM hydraulic motors are widely applied in agriculture machinery, fishing machinery, plastic industry, mining, and construction machinery.


1. An agricultural use: all combine harvesters, seeders, rotary tiller, mower, sprayer, feed mixers, ground drilling machine.


2. fishing with: hauling machine.


3. light industry: winding machines, textile machines, printing presses, operating with a washing machine.


4. construction industry: rollers, cement mixers, cleaning cars.


Main Specifications:

Type BMS
BMSE
80		 BMS
BMSE
100		 BMS
BMSE
125		 BMS
BMSE
160		 BMS
BMSE
200		 BMS
BMSE
250		 BMS
BMSE
315		 BMS
BMSE
375
Geometric displacement
(cm3 /rev.)		 80.6 100.8 125 157.2 200 252 314.5 370
Max. speed (rpm) cont. 800 748 600 470 375 300 240 200
int. 988 900 720 560 450 360 280 240
Max. torque (N·m) cont. 190 240 310 316 400 450 560 536
int. 240 300 370 430 466 540 658 645
peak 260 320 400 472 650 690 740 751
Max. output (kW) cont. 15.9 18.8 19.5 15.6 15.7 14.1 14.1 11.8
int. 20.1 23.5 23.2 21.2 18.3 17 18.9 17
Max. pressure drop (MPa) cont. 17.5 17.5 17.5 15 14 12.5 12 10
int. 21 21 21 21 16 16 14 12
peak 22.5 22.5 22.5 22.5 22.5 20 18.5 14
Max. flow (L/min) cont. 65 75 75 75 75 75 75 75
int. 80 90 90 90 90 90 90 90
Max. inlet pressure (MPa) cont. 25 25 25 25 25 25 25 25
int. 30 30 30 30 30 30 30 30
Weight (kg) 9.8 10 10.3 10.7 11.1 11.6 12.3 12.6

* Continuous pressure :Max. value of operating motor continuously.
* Intermittent pressure :Max. value of operating motor in 6 seconds per minute.
* Peak pressure:Max. value of operating motor in 0.6 second per minute.

Professional Low RPM Hydraulic Motor BMS / 2000 Series 31.75mm Straight Shaft
Professional Low RPM Hydraulic Motor BMS / 2000 Series 31.75mm Straight Shaft
Professional Low RPM Hydraulic Motor BMS / 2000 Series 31.75mm Straight Shaft

Reference Brand List:

HANJIU M+S EATON ROSS WHITE PARKER SAM BOSCH
HYDRAULIC HYDRAULIC CHAR LYNN TRW CROSS BREVINI REXROTH
BMM MM OMM MGX
MLHK J SERIES - - - BGM
BMP/BM1 MP OMP MF WP TC BG MGP, GMP
TE
HP H SERIES DH MG RS TB
BMR/BM2 MR OMR MB WR BR MGR, GMR
HR S,T SERIES DS RE TF
MLHRW, RW W SERIES OMEW
BMH/BM4 MH OMH
MLHH ME
HW, HWF RE TG
BMS/BM5 MS, MSY OMS TG MGS, GMS
HPR
MLHS 2000 SERIES ME RE
BMT/BM6 MT OMT MGT, GMT
MLHT 6000 SERIES MJ HT
MTM TMT
BMV MV OMV MGV, GMV
MLHV 10000 SERIES
