Specifications
Brand Name :
HANJIU
Model Number :
BMER-2-750MDG2B
Certification :
CE
Place of Origin :
CHINA
MOQ :
30 Sets
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
100000 sets per year
Delivery Time :
25 - 30 work days
Packaging Details :
50x21x21cm/ pc/ carton, carton/ pallets
Type :
Hydraulic Wheel Motor
Features :
Replace Parker TE TG TF
Displacement :
750 ml/r (variety size available)
Flange :
4-13.5 Magneto Mount
Ports :
G 1/2
Shaft :
1.25'' (31.75 mm )
Rotation :
Standard
Paint :
Black
Description

Parker TG0475 TG0530 TG0750 Hydraulic Motor BMER475 BMER530 BMER750

Hanjiu High Torque BMER-2-750MDG2B Replaces American Parker Conical Cycloidal Hydraulic Oil Motor

BMER-2-750MDG2B

1, model number BMER-2-750MDG2B
2, displacement 750 ml/r
3, flange 4 - 4-13.5 Magneto Mount
4, shaft 1.25'' ( 31.75 ) mm straight shaft, parrel key
5, oil port G 1/2
6, drain
7, rotation Standard
8, paint Black
9, replace Parker TE TG TF

Main Specificaion

Type BMER BMER BMER BMER BMER BMER BMER BMER BMER BMER BMER
125 160 200 230 250 300 350 375 475 540 750
Geometric displacement (cm3/rev.) 118 156 196 228 257 296 345 371 462 540 745
Max. speed (rpm) cont. 360 375 330 290 290 250 220 200 160 140 100
int. 490 470 425 365 350 315 270 240 195 170 120
Max. torque (N•m) cont. 325 450 530 625 700 810 905 990 1085 980 1050
int. 380 525 600 710 790 930 1035 1140 1180 1240 1180
peak 450 590 750 870 980 1120 1285 1360 1260 1380 1370
Max. output (kW) cont. 12.0 15.0 15.5 16.0 17.5 18.0 17.5 16.5 14.5 11.5 8.0
int. 14.0 17.5 18.0 19.0 20.0 21.0 20.0 19.0 16.5 15.0 10.0
Max. pressure drop (MPa) cont. 20.5 20.5 20.5 20.5 20.5 20.5 20.5 20.5 17.5 14 10.5
int. 24 24 24 24 24 24 24 24 19 17.5 12
peak 27.6 27.6 27.6 27.6 27.6 27.6 27.6 27.6 20.5 20.5 14
Max. flow (L/min) cont. 45 60 70 70 75 80 80 75 75 75 75
int. 60 75 85 85 90 95 95 90 90 90 90

Eaton/ / White/ Parker
101-1001
101-1004
101-1022
101-1031
103-1004
103-1027
103-1030
103-1032
104-1001
104-1002
104-1004
104-1027
104-1028
112-1068
119-1030
119-1031
119-1028
119-1029
TE0065
TE0100
TE0165
TE0195
TG0475
TG0530

Applications:

Wheel Motor Orbital type is one type of high torque low speed hydraulic motors, with high efficiency and long life. Which can be widely used for kinds of Rollers, Heavey Machines, Construction Machines etc. To know more details, like technical data or drawing, pls directly contact us or to download from our main website.
