Specifications
Brand Name :
Pronets or OEM
Model Number :
PPP-318G-02C
Certification :
UL FCC RoHS FDA
Place of Origin :
China
MOQ :
1pcs
Price :
US $
Payment Terms :
T/T
Supply Ability :
10000pcs/day
Packaging Details :
plastic containers
type :
fiber optical active passive product
keyword :
optical transceiver/Network switch/Media converter
Description

PPP-318G-02C 8.5Gb/s SFP+ Fibre Channel Optical Transceiver

Features

  • Up to 8.5Gb/s bi-directional data links
  • Hot Pluggable SFP+ footprint
  • Built-in digital diagnostic functions
  • 1310nm Fabry-Perot laser transmitter
  • Duplex LC connector
  • RoHS compliant and Lead Free
  • Up to 1.4km at 8Gb/s on 9/125um SMF
  • Metal enclosure, for lower EMI
  • Single 3.3V power supply
  • Operating case temperature: -5℃ to 70℃

Applications

  • Tri Rate 2.125/4.25/8.5Gbs Fibre Channel

Product description

Pronets’s PPP-318G-02C SFP+ transceivers are designed for use in Fibre Channel links up to 1.4 km at 8.5 Gb/s data rate. They are compliant with FCPI-4 Rev. 8.001 and SFF-8472 Rev 10.23, and compatible with SFF-84322. Pronets’s PPP-318G-02C Digital diagnostics functions are available via a 2-wire serial interface, as specified in SFF-8472, which allows real-time access to device operating parameters such as transceiver temperature, laser bias current, transmitted optical power, received optical power and transceiver supply voltage. The product is RoHS compliant and lead-free per Directive 2002/95/EC5.
