40km 10G XFP Transceiver DWDM XFP Optical Transceiver XFP MSA Compliant
40km 10G XFP Transceiver DWDM XFP Optical Transceiver XFP MSA Compliant
40km 10G XFP Transceiver DWDM XFP Optical Transceiver XFP MSA Compliant
40km 10G XFP Transceiver DWDM XFP Optical Transceiver XFP MSA Compliant
Specifications
Brand Name :
Pronets or OEM
Model Number :
PXD-XX192- 04C
Certification :
UL FCC RoHS FDA
Place of Origin :
China
MOQ :
1pcs
Price :
US $
Payment Terms :
T/T
Supply Ability :
10000pcs/day
Packaging Details :
plastic containers
type :
fiber optical active passive product
keyword :
optical transceiver/Network switch/Media converter
Description

PXD-XX192- 04C

PRONETS DWDM XFP Optical Transceiver

Features

Wavelength selectable to C-band ITU-T grid wavelengths

Suitable for use in 100GHz channel spacing DWDM systems

XFP MSA Compliant

data rate from 9.95 Gbps to 11.3Gbps No Reference Clock required

Cold Start up Wavelength Compliance

DWDM-rated EML transmitter and PIN receiver

link length up to 40km

Low Power Dissipation 3.5W Maximum

-5ºC to 70ºC Operating Case Temperature

Diagnostic Performance Monitoring of module temperature, supply

Voltages, laser bias current, transmit optical power, receive optical power

RoHS compliant and lead free

Applications

SONET OC-192&SDH STM 64

10GBASE-ER/EW

40 km 10G Fiber Channel

DWDM Networks

Description

PRONETS DWDM XFP Transceiver exhibits excellent wavelength stability, supporting operation at 100 GHz channel, cost effective module. It is designed for 10G DWDM SDH, 10GBASE-ER/EW and 10G Fiber- Channel applications.

The transceiver consists of two sections: The transmitter section incorporates a colded EML laser. And the receiver section consists of a PIN photodiode integrated with a TIA. All modules satisfy class I laser safety requirements. PRONETS DWDM XFP transceiver provides an enhanced monitoring interface, which allows real-time access to device operating parameters such as transceiver temperature, laser bias current, transmitted optical power, received optical power and transceiver supply voltage.
