Shape Customizable Optical Right Angle Glass Crystal Ball Prism
In the specialized field of precision optical components, the Shape Customizable Optical Right Angle Glass Crystal Ball Prism stands out as a unique hybrid of geometric precision and spherical refractive power. Unlike standard components, this solution is designed to offer high-level light manipulation, serving both as a total internal reflection (TIR) element and a high-index lens.
Our manufacturing process involves rigorous fine-grinding and double-sided polishing to ensure sub-micron surface accuracy. By utilizing premium K9 or B270 substrates, each Crystal Ball Prism delivers exceptional clarity, making it indispensable for advanced laser steering, medical imaging, and high-end artistic light installations.
The integration of a spherical face onto a 90-degree substrate creates the Crystal Ball Prism, allowing for the simultaneous redirection and focusing of light beams. This dual-functionality reduces the need for multiple optical elements in compact systems. Furthermore, our customizable capabilities allow clients to specify unique dimensions, focal lengths, and coating types (such as AR or HR coatings) to meet specific project demands.
Technical Specifications
Feature Specification Operational Benefit
Material Substrate Optical Grade K9 / BK7 Glass High homogeneity
Prism Geometry Shape Customizable Right Angle Glass 90° Light deviation
Surface Quality 40-20 to 20-10 Scratch-Dig Low scatter in prism array
Spherical Radius Customizable (R2mm to R100mm) Precise focus control
Angle Tolerance ±3 arc minutes High-fidelity alignment
Dimensional Accuracy ±0.02mm Perfect mechanical fit
Coating Options BBAR, V-Coat, or Uncoated Maximized throughput
Transmission Rate > 98.5% (Coated) Vibrant light output
Shape Customizable Optical Right Angle Glass Crystal Ball Prism
Specification Details
Materials BK7 or other optical glass, quartz, sapphire, Ge, Si, ZnSe, CaF2 etc
Length 3~100mm
Width 3~100mm
Height 3~100mm
Length tolerance ±0.01mm
Width tolerance ±0.01mm
Height tolerance ±0.01mm
Angle tolerance 3"~2'
Irregularity ΔN=0.1~0.5
Surface accuracy N=1~3
Surface quality 10/5~60/40
Coating Upon request
Application area Imaging, Lighting, Laser etc
Shape Customizable Optical Right Angle Glass Crystal Ball Prism
Key Benefits
  • Integrated Focusing Power: Eliminates the need for separate lenses by combining a right angle prism with a spherical refractive surface.
  • Fully Customizable Dimensions: Non-standard sizes available to ensure perfect fit into any proprietary housing.
  • Superior Thermal Stability: High-quality glass maintains optical properties even under fluctuating temperature environments.
Product Images
Shape Customizable Optical Right Angle Glass Crystal Ball Prism Shape Customizable Optical Right Angle Glass Crystal Ball Prism Shape Customizable Optical Right Angle Glass Crystal Ball Prism Shape Customizable Optical Right Angle Glass Crystal Ball Prism
Primary Application Fields
  • Advanced Laser Systems: Utilizing the Crystal Ball Prism for beam expansion and 90-degree redirection in fiber-optic communications.
  • Scientific Medical Imaging: Implementing in endoscopes and dental imaging tools for compact light path bending.
  • Creative Macro Photography: Using as a foreground element to create unique refractive distortions and "rainbow" flares.
  • Sensory and Measurement Tools: Integrating into laser rangefinders and optical encoders.
Frequently Asked Questions
Q1: What is the main benefit of the Shape Customizable Optical Right Angle Glass Crystal Ball Prism over a standard lens?
The primary benefit is the combination of redirection and refraction. While a standard lens only focuses light, the Crystal Ball Prism bends the light path by 90 degrees while simultaneously focusing or dispersing it, which is crucial for functioning in tight spatial configurations.
Q2: Can I request specific coatings for my Shape Customizable Optical Right Angle Glass?
Absolutely. Every Crystal Ball Prism can be treated with Anti-Reflective (AR) coatings to reduce ghosting or High-Reflection (HR) coatings on the hypotenuse to enhance internal reflection efficiency.
Q3: How does "Shape Customizable" apply to the Right Angle Glass?
Our customizable service means we can modify the height, width, and even the spherical radius of the Crystal Ball Prism. This allows the component to be tailored specifically to your unique optical train or aesthetic installation.
Q4: What material is best for a Shape Customizable Optical Right Angle Glass Crystal Ball Prism used in outdoor lighting?
For outdoor durability and high clarity, we recommend K9 glass. It offers an excellent balance of refractive index and environmental resistance, ensuring the prism remains clear over time.
Q5: What is the lead time for a Custom Crystal Ball Prism?
Lead times generally range from 2 to 4 weeks, depending on the complexity of the geometry and the specific coating requirements.
