High Transmission AR Coated Sapphire Optical Window 25.4mm UV IR Grade
High Transmission AR Coated Sapphire Optical Window 25.4mm UV IR Grade
Specifications
Thickness :
1.0mm - 3.0mm Custom
Place of Origin :
Guangdong, China
Material :
Single Crystal Sapphire Al2O3
Payment Terms :
T/T,PayPal,Western Union
Application :
UV IR Imaging and Sensor Systems
Price :
USD 8-50 / Piece
Transmission :
>97% Coated Visible
Packaging Details :
Individual anti-static wrapping with foam insert, export-grade carton
Coating :
Broadband AR Both Sides
Surface Quality :
20-10 Scratch-Dig
Certification :
ISO 9001:2015
MOQ :
10 Pieces
Diameter :
25.4mm
Brand Name :
ECER Optics
Delivery Time :
7-10 working days for stock, 15-20 days for production
Product Name :
High Transmission Sapphire Optical Window
Model Number :
SW-HT-AR25
Supply Ability :
30000 Pieces per Month
Description
High Transmission AR Coated Sapphire Optical Window 25.4mm UV IR Grade
This high transmission AR coated sapphire optical window delivers the light efficiency that precision imaging and sensor systems demand. The 25.4mm window is fabricated from single crystal sapphire and polished on both sides to a 20-10 scratch-dig surface quality, then coated with a broadband anti-reflective layer that lifts transmission above 97 percent across the visible range and maintains strong performance into the UV and IR bands.
Sapphire was selected as the substrate because it combines the transmission performance of an optical window with the mechanical durability of a protective component. The high transmission sapphire window resists scratching, thermal shock, and chemical attack, which makes it suitable for applications where the window is exposed to cleaning, weather, or process environments.
Technical Specifications
Product Name High Transmission AR Coated Sapphire Optical Window
Material Single Crystal Sapphire Al2O3
Diameter 25.4mm (Custom 5-200mm)
Thickness 1.0mm - 3.0mm Custom
Coating Broadband AR Both Sides
Transmission >97% Coated Visible, >85% UV-IR
Surface Quality 20-10 Scratch-Dig
Flatness Lambda/4 @ 632.8nm
Application UV IR Imaging and Sensor Systems
Certificate RoHS Compliant, ISO 9001:2015
Key Advantages
  • Broadband AR coating lifts transmission above 97 percent in the visible range
  • Single crystal sapphire substrate covers UV through IR wavelengths
  • 20-10 surface quality minimizes scattering for clean imaging
  • High transmission sapphire window reduces the need for brighter illumination
  • Durable surface survives repeated cleaning without performance loss
  • Measured transmission curve supplied with every production batch
  • Custom diameter, thickness, and coating wavelengths available
  • Ideal for camera modules, optical sensors, and laboratory instruments
Typical installations include industrial camera housings, spectroscopy equipment, laser delivery systems, and outdoor sensor enclosures where a high transmission sapphire window protects the optics while preserving signal strength. Because the AR coated sapphire optical window is specified with both optical and mechanical performance in mind, design teams can use a single component for protection and imaging instead of stacking separate parts.
Product Q&A
Q: How much does the AR coating improve transmission?
Uncoated sapphire reflects about 7 percent per surface, losing roughly 14 percent total. The broadband AR coating on this sapphire optical window reduces reflection to under 1.5 percent per surface, raising total transmission above 97 percent in the visible band and above 85 percent across the UV and IR ranges where sapphire naturally transmits.
Q: Can the coating be optimized for a specific wavelength?
Yes. The standard broadband AR design covers 400-700nm, but we regularly produce coatings centered on 1064nm for laser systems, 3-5um for MWIR cameras, and dual-band designs for fluorescence or multi-spectral instruments. Provide your operating wavelength and we will tune the coating stack.
Q: Why choose sapphire over fused silica or BK7 for a window?
Sapphire offers Mohs 9 hardness, roughly three times the mechanical strength of fused silica, and superior chemical resistance, while still transmitting from the UV through the mid-infrared. If your window must survive harsh environments and still deliver high transmission, sapphire is the balanced choice.
Q: What inspection data is included with the windows?
Each batch ships with surface quality inspection records, dimensional certificates, coating adhesion test results, and a measured spectral transmission curve. This documentation supports incoming inspection and medical or industrial quality programs.
