Density Network 40G Multimode Bare Fiber High Performance 100G Multimode Fiber -65°C To 85°C
Density Network 40G Multimode Bare Fiber High Performance 100G Multimode Fiber -65°C To 85°C
Density Network 40G Multimode Bare Fiber High Performance 100G Multimode Fiber -65°C To 85°C
Density Network 40G Multimode Bare Fiber High Performance 100G Multimode Fiber -65°C To 85°C
Specifications
Wavelength :
850/1300nm
Attenuation :
2.4dB/km @850nm, 0.6dB/km @1300nm
Price :
Negotiation
Name :
40G Multimode Bare Fiber
Fiber Type :
Multimode
Operating Temperature :
-65°C To +85°C
Place of Origin :
Netherland
MOQ :
4400m
Payment Terms :
T/T
Supply Ability :
3000km/month
Delivery Time :
2-8 work days
Packaging Details :
Carton Packing
Fiber Core Size :
50/125 Microns
Brand Name :
Prysmian
Model Number :
OM4 Bare Fibre
Place Of Origin :
Netherlands
Bandwidth :
4700 MHz*km @850nm, 500 MHz*km @1300nm
Description
Density Network 40G Multimode Bare Fiber High Performance 100G Multimode Fiber -65°C To 85°C
Product Overview

OM4 Bare Fiber is a high-performance optical fiber designed for modern networking applications. With a 50/125 micron fiber core size, this multimode fiber delivers exceptional bandwidth capabilities for high-speed data transmission in data centers, enterprises, and demanding networking environments.

Key Specifications:
• Bandwidth: 4700 MHz*km @850nm / 500 MHz*km @1300nm
• Operating Temperature: -65°C to +85°C
• Wavelength: 850/1300nm
• Differential Mode Delay (DMD): ≤2ps/m
• 10G/40G/100G/400G Compatible
Technical Specifications
Parameter Specification
Product Name OM4 Bare Fiber
Fiber Type Multimode
Fiber Core Size 50/125 Microns
Wavelength 850/1300nm
Operating Temperature -65°C to +85°C
Attenuation @850nm 2.4dB/km
Attenuation @1300nm 0.6dB/km
DMD ≤2ps/m
Compatibility 10G/40G/100G/400G
Fiber Standard Gen 2 Laser-Optimized Fiber (OM4)
Applications

Prysmian OM4 Bare Fibre is engineered for high-speed data transmission across various demanding applications:

  • High-density data centers requiring superior bandwidth performance
  • Enterprise networking environments with demanding connectivity requirements
  • Indoor networking setups requiring high bandwidth capacity
  • Outdoor installations with rugged protection (Armored Outdoor OM4 variant available)
  • Applications requiring reliable performance in extreme temperature conditions
  • Networks supporting 400GBase-SR8/FR4 standards (OM4: 50m)
Support & Services

Our comprehensive technical support and services ensure optimal performance and customer satisfaction. Our expert team provides assistance with installation, troubleshooting, and maintenance, along with training resources to maximize product utilization.
