12 Core Cold Rolled Steel Fiber Optic Din Rail Terminal Box With Lc Duplex Adapter
12 Core Cold Rolled Steel Fiber Optic Din Rail Terminal Box With Lc Duplex Adapter
12 Core Cold Rolled Steel Fiber Optic Din Rail Terminal Box With Lc Duplex Adapter
12 Core Cold Rolled Steel Fiber Optic Din Rail Terminal Box With Lc Duplex Adapter
12 Core Cold Rolled Steel Fiber Optic Din Rail Terminal Box With Lc Duplex Adapter
12 Core Cold Rolled Steel Fiber Optic Din Rail Terminal Box With Lc Duplex Adapter
12 Core Cold Rolled Steel Fiber Optic Din Rail Terminal Box With Lc Duplex Adapter
12 Core Cold Rolled Steel Fiber Optic Din Rail Terminal Box With Lc Duplex Adapter
12 Core Cold Rolled Steel Fiber Optic Din Rail Terminal Box With Lc Duplex Adapter
12 Core Cold Rolled Steel Fiber Optic Din Rail Terminal Box With Lc Duplex Adapter
12 Core Cold Rolled Steel Fiber Optic Din Rail Terminal Box With Lc Duplex Adapter
12 Core Cold Rolled Steel Fiber Optic Din Rail Terminal Box With Lc Duplex Adapter
Specifications
Brand Name :
Twilight Optic
Model Number :
TW-DRB02-6LCDX
Place of Origin :
Guangdong
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000pcs per week
Delivery Time :
7-15 working days
Packaging Details :
30pcs/Carton,GW:24kg,Carton size:60*33*37cm
Name :
Fibre Optic DIN Rail Mount Enclosure
Dimensions :
129*130*40MM
Material :
Cold-roll steel
Protection level :
IP20
Color :
Gray
Cable Entry Port :
2pcs
Pigtails :
12 pcs
Application :
FTTH FTTB FTTX Network
Description

12 Core Cold Rolled Steel Fiber Optic Din Rail Terminal Box With Lc Duplex Adapter

The Fibre Optic Terminal Box with DIN Rail is available for connection, distribution and termination of various types of fibre optic systems. It is particularly suitable for terminal distribution in mini-networks in which optical cables, patch cores or pigtails are connected. All DIN Rail terminal boxes can be fully equipped.

Features:
● Integrated splice holders (fusion splices)
● 2pcs cable entry/exit ports; 12pcs pigtail entry/exit ports
● IP20 protection
● Rear or aside DIN rail fixation
● 2x rear entries (PG 11 cable gland)
● Grey color

Specification:

Dimension Material Adapter port Splicing capacity Cable port Application
129*130*40mm Cold-Roll Steel 6 LC Duplex Max. 12 fibers 4 ports DIN rail mounted

Accessories:

Item Name Specification Unit Qty
1 Heat shrinkable protection sleeves 45*2.6*1.2mm pcs As per using capacity
2 Cable tie 3*120mm white pcs 2

Application:
Suitable for Pigtail, ribbon and bunch cable connect distribution Used for wall-mounted applications.
Used in FTTH, Telecommunications, CATV etc.

12 Core Cold Rolled Steel Fiber Optic Din Rail Terminal Box With Lc Duplex Adapter12 Core Cold Rolled Steel Fiber Optic Din Rail Terminal Box With Lc Duplex Adapter12 Core Cold Rolled Steel Fiber Optic Din Rail Terminal Box With Lc Duplex Adapter12 Core Cold Rolled Steel Fiber Optic Din Rail Terminal Box With Lc Duplex Adapter12 Core Cold Rolled Steel Fiber Optic Din Rail Terminal Box With Lc Duplex Adapter

12 Core Cold Rolled Steel Fiber Optic Din Rail Terminal Box With Lc Duplex Adapter
