Premium Indoor Access Point AP7030DE Huawei Dual Band Smart AP Indoor Double Frequency
Premium Indoor Access Point AP7030DE Huawei Dual Band Smart AP Indoor Double Frequency
Premium Indoor Access Point AP7030DE Huawei Dual Band Smart AP Indoor Double Frequency
Premium Indoor Access Point AP7030DE Huawei Dual Band Smart AP Indoor Double Frequency
Specifications
Brand Name :
HUAWEI
Model Number :
AP7030DE
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 UNIT
Price :
Negotiable
Payment Terms :
T/T, Western Union, Paypal
Supply Ability :
100 UNITS/MONTH
Delivery Time :
1-2 DAYS
Packaging Details :
NEW IN BOX
Part number :
AP7030DE
Brand :
HUAWEI
Power Input :
12V DC ±10% PoE: −48V DC
Operating Temperature :
−20°C to 50°C
Radio Protocols :
802.11a/b/g/n/ac
Maximum Rate :
1.9 Gbit/s
Description

AP7030DE Huawei Dual-band Premium Indoor Access point Smart AP Indoor Double Frequency


AP7030DE Overview

Huawei AP7030DE is a dual-band wireless access point which provides secure gigabit wireless access in compliance with 802.11ac standards. The Huawei AP7030DE AP delivers high-powered performance in a rugged, attractive enclosure which is ideal for high-capacity wireless connectivity in large venues, such as public or private assembly halls and convention centers. Built-in smart antenna arrays provide WLAN throughput up to 1.9 Gbit/s with optimum indoor coverage and also supports fine-grained user management, real-time AP management and maintenance, and plug-and-play deployment.



AP7030DE Specification

AP7030DE Specifications

Technical
Dimensions (H × W × D)2.1 in. x 8.7 in. x 8.7 in. (53 mm x 220 mm x 220 mm)
Weight2.4 lb. (1.1 kg)
System memory

256 MB DDR3
32 MB Flash

Power
Power input

DC 12V ± 10%
POE Power: -48V DC.
PoE function IEEE compliant802.3at

Maximum power consumption

19W
Note: Maximum power consumption depends on local laws and regulations

Environment
Operating temperature-4°F to 122°F (-20°C to 50°C)
Storage temperature-40°F to 158°F (-40°C to 70°C)
Humidity5% to 95% (Non-condensing)
Waterproof gradeIP41
Altitude–60m to 5,000m
Radio specifications
Antenna TypeBuilt-in dual-band (up to 12 antennas)
Antenna Gain

2.4G: 5 dBi
5G: 5 dBi

Maximum Number of Concurrent Users≤ 256
Maximum Transmit Power

20 dBm
You can lower transmit power to 20 dB maximum in 1 dB increments
Note: Actual transmit power depends on local laws

Maximum Number of Non-overlapping Channels

2.4 GHz
802.11b/g
·20 MHz: 3
802.11n
·20 MHz: 3
·40 MHz: 1
5 GHz
802.11a
·20 MHz: 5
802.11n
·20 MHz: 5
·40 MHz: 2
802.11ac
·20 MHz: 5
·40 MHz: 2
·80 MHz: 1
Note: The number of non-overlapping channels allowed varies in different countries. For details, see the Country Codes and Channels compliance status

Channel Rates802.11b: 1, 2, 5.5, and 11 Mbit/s
802.11a/g: 6, 9, 12, 18, 24, 36, 48, and 54 Mbit/s

802.11n data rate (2.4 GHz and 5 GHz): 6.5 Mbit/s to 600 Mbit/s
802.11ac data rate (5 GHz): 6.5 Mbit/s to 1,300 Mbit/s

Receiver Sensitivity

2.4 GHz
802.11b (CCK)
-97 dBm @ 1 Mbit/s
-92 dBm @ 2 Mbit/s
-93 dBm @ 5.5 Mbit/s
-89 dBm @ 11 Mbit/s

2.4 GHz
802.11g (non-HT20)
-91 dBm @ 6 Mbit/s
-90 dBm @ 9 Mbit/s
-90 dBm @ 12 Mbit/s
-88 dBm @ 18 Mbit/s
-84 dBm @ 24 Mbit/s
-81 dBm @ 36 Mbit/s
-77 dBm @ 48 Mbit/s
-74 dBm @ 54 Mbit/s

2.4 GHz
802.11n (HT20):
-90 dBm @ MCS1
-88 dBm @ MCS2
-82 dBm @ MCS3
-79 dBm @ MCS4
-75 dBm @ MCS5
-73 dBm @ MCS6
-72 dBm @ MCS7
-87 dBm @ MCS8
-86 dBm @ MCS9
-86 dBm @ MCS10
-83 dBm @ MCS11
-79 dBm @ MCS12
-75 dBm @ MCS13
-74 dBm @ MCS14
-73 dBm @ MCS15
-87 dBm @ MCS16
-86 dBm @ MCS17
-86 dBm @ MCS18
-83 dBm @ MCS19
-79 dBm @ MCS20
-75 dBm @ MCS21
-74 dBm @ MCS22
-73 dBm @ MCS23

2.4 GHz
802.11n (HT40):
-86 dBm @ MCS0
-86 dBm @ MCS1
-84 dBm @ MCS2
-80 dBm @ MCS3
-77 dBm @ MCS4
-72 dBm @ MCS5
-70 dBm @ MCS6
-68 dBm @ MCS7
-86 dBm @ MCS8
-86 dBm @ MCS9
-84 dBm @ MCS10
-80 dBm @ MCS11
-77 dBm @ MCS12
-72 dBm @ MCS13
-71 dBm @ MCS14
-70 dBm @ MCS15
-86 dBm @ MCS16
-86 dBm @ MCS17
-84 dBm @ MCS18
-80 dBm @ MCS19
-77 dBm @ MCS20
-72 dBm @ MCS21
-71 dBm @ MCS22
-70 dBm @ MCS23

5 GHz
802.11a (non-HT20)
-91 dBm @ 6 Mbit/s
-90 dBm @ 9 Mbit/s
-89 dBm @ 12 Mbit/s
-86 dBm @ 18 Mbit/s
-83 dBm @ 24 Mbit/s
-80 dBm @ 36 Mbit/s
-75 dBm @ 48 Mbit/s
-74 dBm @ 54 Mbit/s

5 GHz
802.11n (HT20)
-90 dBm @ MCS0
-88 dBm @ MCS1
-86 dBm @ MCS2
-81 dBm @ MCS3
-78 dBm @ MCS4
-74 dBm @ MCS5
-72 dBm @ MCS6
-71 dBm @ MCS7
-89 dBm @ MCS8
-86 dBm @ MCS9
-84 dBm @ MCS10
-80 dBm @ MCS11
-77 dBm @ MCS12
-72 dBm @ MCS13
-70 dBm @ MCS14
-69 dBm @ MCS15
-89 dBm @ MCS16
-86 dBm @ MCS17
-84 dBm @ MCS18
-80 dBm @ MCS19
-77 dBm @ MCS20
-72 dBm @ MCS21
-70 dBm @ MCS22
-69 dBm @ MCS23

5 GHz
802.11n (HT40)
-87 dBm @ MCS0
-85 dBm @ MCS1
-83 dBm @ MCS2
-79 dBm @ MCS3
-75 dBm @ MCS4
-71 dBm @ MCS5
-68 dBm @ MCS6
-67 dBm @ MCS7
-86 dBm @ MCS8
-83 dBm @ MCS9
-81 dBm @ MCS10
-76 dBm @ MCS11
-73 dBm @ MCS12
-69 dBm @ MCS13
-68 dBm @ MCS14
-66 dBm @ MCS15
-86 dBm @ MCS16
-83 dBm @ MCS17
-81 dBm @ MCS18
-76 dBm @ MCS19
-73 dBm @ MCS20
-69 dBm @ MCS21
-68 dBm @ MCS22
-66 dBm @ MCS23

5 GHz
802.11ac (VTH20)
-89 dBm @ MCS0NSS1
-86 dBm @ MCS1NSS1
-84 dBm @ MCS2NSS1
-80 dBm @ MCS3NSS1
-77 dBm @ MCS4NSS1
-73 dBm @ MCS5NSS1
-71 dBm @ MCS6NSS1
-70 dBm @ MCS7NSS1
-65 dBm @ MCS8NSS1

5 GHz
802.11ac (VTH40)
-86 dBm @ MCS0NSS1
-83 dBm @ MCS1NSS1
-81 dBm @ MCS2NSS1
-77 dBm @ MCS3NSS1
-74 dBm @ MCS4NSS1
-70 dBm @ MCS5NSS1
-68 dBm @ MCS6NSS1
-67 dBm @ MCS7NSS1
-63 dBm @ MCS8NSS1
-60 dBm @ MCS9NSS1

5 GHz
802.11ac (VTH80)
-82 dBm @ MCS0NSS1
-80 dBm @ MCS1NSS1
-78 dBm @ MCS2NSS1
-74 dBm @ MCS3NSS1
-71 dBm @ MCS4NSS1
-66 dBm @ MCS5NSS1
-65 dBm @ MCS6NSS1
-64 dBm @ MCS7NSS1
-59 dBm @ MCS8NSS1
-57 dBm @ MCS9NSS1
