Specifications
Brand Name :
Huawei
Model Number :
SFP-10G-ZR
Certification :
CE
Place of Origin :
China
Model :
SFP-10G-ZR
Transceiver form factor :
SFP
Transmission speed :
10 Gbit/s
Center wavelength (nm) :
1550mm
Optical fiber type :
SMF
Cable Distance :
80 km
Dimensions :
8.5 x 13.4 x 56.5mm.
Condition :
New Factory Sealed
Warranty :
1 year
Shipment :
DHL, Fedex, UPS
Payment :
T/T, Western Union, Paypal
Description
Huawei SFP-10G-ZR Optical Transceiver Module
The Cisco SFP-10G-ZR is a multi-rate 10GBASE-ZR, 10GBASE-ZW, and OTU2/OTU2e optical transceiver module designed for high-performance networking applications. This module supports link lengths of up to 80 kilometers on standard Single-Mode Fiber (SMF, G.652) and is engineered according to Cisco specifications for optimal performance.
Huawei SFP-10G-ZR Optical Transceiver Module 10G SFP+ Module with 80 km Cable Distance 1550nm Wavelength for Single-Mode Fiber Huawei SFP-10G-ZR Optical Transceiver Module 10G SFP+ Module with 80 km Cable Distance 1550nm Wavelength for Single-Mode Fiber
Quick Specifications
Specification Value
Model Cisco SFP-10G-ZR
Wavelength (nm) 1550
Cable Type SMF
Core Size (Microns) G.652
Modal Bandwidth (MHz*km) -
Cable Distance 80km
* Requires 15dB attenuator if Link Distance < 5km. Requires 10dB attenuator if Link Distance is between 5km and 15km. Requires 5dB attenuator if Link Distance is between 15km and 25km.
** Specified at transmission wavelength.
*** Minimum cabling distance for -SR, -LRM, -LR, -ER modules is 2m, according to the IEEE 802.3ae.
Platform Support
This optical transceiver module is compatible with the following Cisco platforms:
  • 7600 Series Router
  • ASR-903
  • ASR 1000 Series Router
  • ASR 9000 Series Router
  • Catalyst 2960-S, 2960-X, and 2960-XR Series Switches
  • Catalyst 3850 Series Switches
  • Catalyst 4500 and 4500-X Series Switches
  • Nexus 2000, 3000 Series Switches
  • Nexus 9000 and 9500 (modular) Series Switches
Comparison with Similar SFP+ Modules
Cisco SFP+ Wavelength (nm) Cable Type Core Size (Microns) Modal Bandwidth (MHz*km) Cable Distance
Cisco SFP-10G-SR 850 MMF 62.5 160 (FDDI) 26m
Cisco SFP-10G-SR-X 850 MMF 50 400 66m
Cisco SFP-10G-LRM 1310 MMF/SMF 62.5/50 500 220m
Cisco SFP-10G-LR 1310 SMF G.652 - 10km
Cisco SFP-10G-ER 1550 SMF G.652 - 40km
Cisco SFP-10G-ZR 1550 SMF G.652 - 80km
Technical Specifications
SFP+ Port Cabling Specifications
Wavelength (nm) 1550
Cable Type SMF
Core Size (Microns) G.652
Modal Bandwidth (MHz*km) -
Cable Distance 80km
Optical Transmit and Receive Specifications
Type 10GBASE-ZR 1550nm SMF
Transmit Power (dBm) 4.0 (Max), 0 (Min)
Receive Power (dBm) -7 (Max), -24 (Min)
Transmit and Receive Wavelength (nm) 1530 to 1565
Other Specifications
Bail Latch Color Green
Power Consumption (W) 1.5
Dimensions 8.5 x 13.4 x 56.5mm (H x W x D)
Weight 75 grams or less
Operating Temperature Ranges
  • Commercial temperature range (COM): 0 to 70°C (32 to 158°F)
  • Extended temperature range (EXT): -5 to 85°C (23 to 185°F)
  • Industrial temperature range (IND): -40 to 85°C (-40 to 185°F)
  • Storage temperature range: -40 to 85°C (-40 to 185°F)
