Huawei CloudEngine S5755‑H48T4Y2CZ 48‑Port Gigabit Switch with 25GE/100GE Uplinks for Campus & Data Center
Huawei CloudEngine S5755‑H48T4Y2CZ 48‑Port Gigabit Switch with 25GE/100GE Uplinks for Campus & Data Center
Huawei CloudEngine S5755‑H48T4Y2CZ 48‑Port Gigabit Switch with 25GE/100GE Uplinks for Campus & Data Center
Huawei CloudEngine S5755‑H48T4Y2CZ 48‑Port Gigabit Switch with 25GE/100GE Uplinks for Campus & Data Center
Huawei CloudEngine S5755‑H48T4Y2CZ 48‑Port Gigabit Switch with 25GE/100GE Uplinks for Campus & Data Center
Huawei CloudEngine S5755‑H48T4Y2CZ 48‑Port Gigabit Switch with 25GE/100GE Uplinks for Campus & Data Center
Specifications
Brand Name :
Huawei
Model Number :
S5755-H48T4Y2CZ
Certification :
CE
Place of Origin :
CHINA
MOQ :
1
Payment Terms :
T/T
Delivery Time :
2-3 days
Product Name :
Switch
Part Number :
S5755-H48T4Y2CZ
Payment :
TT
Shipment :
DHL
Condition :
New
Lead Time :
2-3days
Warranty :
1 year
Keywords :
S5755-H48T4Y2CZ
Description

Huawei S5755-H48T4Y2CZ Overview

The Huawei CloudEngine S5755‑H48T4Y2CZ is a high‑performance, high‑density gigabit access switch designed for modern campus networks and data center edge deployment. It delivers 48 fixed 10/100/1000Base‑T ports for end‑device connectivity, paired with four 25GE SFP28 and two 100GE QSFP28 uplink ports to support high‑bandwidth aggregation and interconnection




Figure 1 shows the front panel of S5736-S24S4XC.
Huawei CloudEngine S5755‑H48T4Y2CZ 48‑Port Gigabit Switch with 25GE/100GE Uplinks for Campus & Data Center
Huawei CloudEngine S5755‑H48T4Y2CZ 48‑Port Gigabit Switch with 25GE/100GE Uplinks for Campus & Data Center




Quick Specs
Item Details
Model CloudEngine S5755‑H48T4Y2CZ
Fixed Ports 48×10/100/1000Base‑T, 4×25GE SFP28, 2×100GE QSFP28
Switching Capacity 944 Gbps / 2.4 Tbps
Forwarding Performance 450 Mpps
Chassis 1U, 442×420×43.6 mm
Weight 7.83 kg
Power 1+1/N+1 backup, AC/DC support
Key Features VXLAN, MACsec, IPv4/IPv6 dual stack, M‑LAG










Huawei S5755-H48T4Y2CZ Specification

Parameter Specification
Basic Info
Product Name Huawei CloudEngine S5755‑H48T4Y2CZ Switch
Port Configuration 48×10/100/1000Base‑T Ethernet ports

4×1/10/25GE SFP28 ports

2×40/100GE QSFP28 ports

1 expansion slot
Switching Capacity 944 Gbps (full duplex) / 2.4 Tbps
Forwarding Rate 450 Mpps
Physical
Dimensions (W×D×H) 442 mm × 420 mm × 43.6 mm (1U)
Weight 7.83 kg
Power
Power Supply 180W AC, 600W AC, 1200W DC (pluggable)

1+1 or N+1 redundancy
Input Voltage AC: 100–130V / 200–240V, 50/60Hz

DC: –48V to –60V
Power Consumption ~92W (full ports, dual power)
Environment
Operating Temp –5°C to 45°C
Storage Temp –40°C to 70°C
Humidity 5%–95% (non‑condensing)
Software Features
Network Virtualization VXLAN, BGP‑EVPN, UVF
Reliability M‑LAG, stack, hot‑swap, graceful restart
Security MACsec, 802.1X, ACL, port security
QoS Traffic classification, policing, scheduling, congestion management
Management CLI, Web, SNMP, NETCONF/YANG, CampusInsight
Protocols IPv4/IPv6 dual stack, OSPF, BGP, VLAN, STP/RSTP/MSTP

Huawei CloudEngine S5755‑H48T4Y2CZ 48‑Port Gigabit Switch with 25GE/100GE Uplinks for Campus & Data Center
