Specifications
Brand Name :
Huawei
Model Number :
S5735-L8P4S-A1
Certification :
CE
Place of Origin :
China
Model :
S5735-L8P4S-A1
Ports :
8 x 10/100/1000Base-T ports, 4 x GE SFP ports AC power supply PoE+
Flash memory :
512 MB
Power supply mode :
AC built-in
Net weight :
2.25 kg
Condition :
Brand New Sealed
Warranty :
1 year
Lead time :
2-4 days
Payment :
T/T, Western Union, Paypal
Shipping :
DHL, Fedex, UPS
Description

S5735-L8P4S-A1 Overview

S5735-L8P4S-A1, Huawei S5700 Series Switches

FutureMatrix S5735-L series switches are ideal for scenarios such as enterprise campus network access and gigabit to the desktop. Built on next-generation, high-performance hardware and the Huawei Versatile Routing Platform (VRP), FutureMatrix S5735-L switches stand out with compelling features such as intelligent stack (iStack), flexible Ethernet networking, and diversified security control. They support multiple Layer 3 routing protocols and provide high performance and service processing capabilities.

S5735-L8P4S-A1 FutureMatrix S5735-L8P4S-A1 Switch With 8-Ports 10/100/1000BASE-T 4-Ports GE SFP 1 AC Power FixedS5735-L8P4S-A1 FutureMatrix S5735-L8P4S-A1 Switch With 8-Ports 10/100/1000BASE-T 4-Ports GE SFP 1 AC Power Fixed

S5735-L8P4S-A1 Specification

S5735-L8P4S-A1 Specification
Model S5735-L8P4S-A1
Chassis height [U] 1 U
Weight without packaging [kg(lb)] 2.25 kg (4.96 lb)
Weight with packaging [kg(lb)] 3.17 kg (6.99 lb)
Typical power consumption [W] 28.4 W
Typical heat dissipation [BTU/hour] 96.9 BTU/hour
MTBF [year] 66.56 year
MTTR [hour] 2 hour
Availability >0.99999
Noise at normal temperature (acoustic power) [dB(A)] 42.2 dB(A)
Noise at normal temperature (acoustic pressure) [dB(A)] 30.5 dB(A)
Number of card slots 0
Number of power slots 0
Number of fans modules 1
Redundant power supply Not supported
Power supply mode AC built-in
Rated input voltage [V] 100 V AC to 240 V AC, 50/60 Hz
Input voltage range [V] 90 V AC to 290 V AC, 45 Hz to 65 Hz
Maximum input current [A] 3:00 AM
Memory 512 MB
Flash memory 512 MB
Console port RJ45
Eth Management port Not supported
USB Not supported
RTC Not supported
RPS input Not supported
PoE Supported

S5735-L8P4S-A1 FutureMatrix S5735-L8P4S-A1 Switch With 8-Ports 10/100/1000BASE-T 4-Ports GE SFP 1 AC Power Fixed
