The Cisco Catalyst 3650 series is the enterprise-class standalone and stackable access-layer switch that provides the foundation for full convergence between wired and wireless on a single platform. The Cisco Catalyst 3650 is built on the advanced Cisco StackWise-160, and takes advantage of the Cisco Unified Access Data Plane (UADP) application-specific integrated circuit (ASIC). This switch can enable uniform wired-wireless policy enforcement, application visibility, flexibility, application optimization, and superior resiliency. The Cisco Catalyst 3650 series switch supports full IEEE 802.3at Power over Ethernet Plus (PoE+), and offers modular and field-replaceable redundant fans and power supplies. It can help you increase wireless productivity and reduce your TCO.
|  			 Product Code  			 |  			 			 WS-C3650-48FS-S  			 |
|  			 Enclosure Type  			 |  			 			 Rack-mountable - 1U  			 |
|  			 Feature Set  			 |  			 			 IP Base  			 |
|  			 Uplink Interfaces  			 |  			 			 4 x 1G SFP  			 |
|  			 Ports  			 |  			 			 48 x 10/100/1000 (POE+)  			 |
|  			 Available PoE Power  			 |  			 			 775W  			 |
|  			 Maximum stacking number  			 |  			 			 9  			 |
|  			 Stack bandwidth  			 |  			 			 160 Gbps  			 |
|  			 Forwarding Performance  			 |  			 			 77.37Mpps  			 |
|  			 Switching Capacity  			 |  			 			 176 Gbps  			 |
|  			 RAM  			 |  			 			 4 G  			 |
|  			 Flash Memory  			 |  			 			 2 G  			 |
The Modules, Licenses and Accessories
Table 2 shows some recommended modules, licenses and accessories of this switch.
|  			 Models  			 |  			 			 Description  			 |
|  			 C3650-STACK-KIT=  			 |  			 			 Cisco Catalyst 3650 Stack Module Spare  			 |
|  			 L-C3650-48-S-E=  			 |  			 			 C3650-48 IP Base to IP Services Electronic RTU License  			 |
|  			 PWR-C2-1025WAC=  			 |  			 			 1025W AC Config 2 Secondary Power Supply  			 |
|  			 PWR-C2-640WDC=  			 |  			 			 640W DC Config 2 Secondary Power Supply  			 |
|  			 CAB-CONSOLE-RJ45  			 |  			 			 Console Cable 6ft with RJ45 and DB9F  			 |
|  			 CAB-CONSOLE-USB  			 |  			 			 Console Cable 6 ft with USB Type A and mini-B  			 |
