Hilink HL-QSFP28-100G-UD-20 100Gb/s 20km QSFP28 BIDI LR1 Optical Transceiver Module with Hot Pluggable LC Connector
Hilink HL-QSFP28-100G-UD-20 100Gb/s 20km QSFP28 BIDI LR1 Optical Transceiver Module with Hot Pluggable LC Connector
Hilink HL-QSFP28-100G-UD-20 100Gb/s 20km QSFP28 BIDI LR1 Optical Transceiver Module with Hot Pluggable LC Connector
Hilink HL-QSFP28-100G-UD-20 100Gb/s 20km QSFP28 BIDI LR1 Optical Transceiver Module with Hot Pluggable LC Connector
Hilink HL-QSFP28-100G-UD-20 100Gb/s 20km QSFP28 BIDI LR1 Optical Transceiver Module with Hot Pluggable LC Connector
Hilink HL-QSFP28-100G-UD-20 100Gb/s 20km QSFP28 BIDI LR1 Optical Transceiver Module with Hot Pluggable LC Connector
Hilink HL-QSFP28-100G-UD-20 100Gb/s 20km QSFP28 BIDI LR1 Optical Transceiver Module with Hot Pluggable LC Connector
Hilink HL-QSFP28-100G-UD-20 100Gb/s 20km QSFP28 BIDI LR1 Optical Transceiver Module with Hot Pluggable LC Connector
Hilink HL-QSFP28-100G-UD-20 100Gb/s 20km QSFP28 BIDI LR1 Optical Transceiver Module with Hot Pluggable LC Connector
Hilink HL-QSFP28-100G-UD-20 100Gb/s 20km QSFP28 BIDI LR1 Optical Transceiver Module with Hot Pluggable LC Connector
Specifications
Brand Name :
Hilink
Model Number :
HL-QSFP28-100G-UD-20
Certification :
CE RoHs
Place of Origin :
Guangdong, China
MOQ :
1pcs
Price :
Negotiable
Payment Terms :
L/C,T/T,Western Union
Delivery Time :
5-8 Working days
Packaging Details :
Normal Package Or OEM
Product name :
100G QSFP28 BIDI 20km
Data Rate :
100G
Distance :
20km
Warranty :
3 years
DDM :
Yes
Delivery time :
3-7workingdays
OEM :
Support
Description
Hilink HL-QSFP28-100G-UD-20 100Gb/s 20km QSFP28 BIDI LR1 Transceiver Hot Pluggable Duplex LC Connector Single mode
Key Features

  • QSFP28 MSA compliant

  • 100G Lambda MSA 100G-LR1 Specification compliant Interoperable with IEEE 802.3cu
  • Supports 53.125Gbaud
  • Simplex LC connector
  • 4x25G electrical interface (OIF CEI-28G-VSR)
  • Single +3.3V power supply operating, Maximum power consumption 4.5W

  • Temperature range 0°C to 70°C

  • RoHS Compliant

Applications

  • Data Center Interconnect

  • 100G Ethernet

  • Enterprise networking

Descriptions

HL-QSFP28-100G-UD-20 provides 100GBase-BX throughput up to 20km over single-mode fiber (SMF) using a wavelength of 1290nm-TX/1310nm-RX via an LC connector. The design is compliant to 100GbASE-LR1 of the IEEE 802.3-2012 Clause 88 standard IEEE 802.3cu CAUI-4 chip to module electrical standard ITU-T G.959.1-2012-02 standard . The module converts 4 inputs channels (ch) of 25Gbps electrical data to 1 lane optical signal channel for 100Gb/s(PAM4) optical transmission. Reversely, on the receiver side, the module a optical 100Gb/s(PAM4) input into 1 lane signal, and converts them to 4 lanes output electrical data.

Hilink HL-QSFP28-100G-UD-20 100Gb/s 20km QSFP28 BIDI LR1 Optical Transceiver Module with Hot Pluggable LC Connector
Hilink HL-QSFP28-100G-UD-20 100Gb/s 20km QSFP28 BIDI LR1 Optical Transceiver Module with Hot Pluggable LC Connector
