Specifications
Brand Name :
Hilink
Model Number :
HL-DWSFP10G-ER
Certification :
RoHS
Place of Origin :
Guangdong, China
MOQ :
1pcs
Price :
Negotiable
Payment Terms :
L/C,T/T,Western Union
Delivery Time :
5-8 Working days
Packaging Details :
Normal Package Or OEM
Product name :
10G DWDM SFP+ 40KM
Data Rate :
10G
Wavelength :
CH17~61
Distance :
40km
Warranty :
3 years
Delivery time :
3-7workingdays
OEM :
Support
Description
10G SFP+ DWDM SFP 40km 100GHZ CH17~61 Optional Optical Transceiver Compatible Module Duplex LC Commerical Industrial
HILINK' 10G DWDM SFP+ 40KM Enhanced Small Form Factor Pluggable SFP+ transceivers are designed for use in 10-Gigabit Ethernet links up to 40km over Single Mode fiber. They are compliant with SFF- 8431,SFF-8432 and ITU-T G.698.1. The transceiver designs are optimized for high performance and cost effective to supply customers the best solutions for telecommunication.
This transceiver consists of two sections: The transmitter section incorporates a cooled EML laser. And the receiver section consists of a PIN photodiode integrated with a TIA. All modules satisfy class I laser safety requirements. Digital diagnostics functions are available via a 2-wire serial interface, as specified in SFF-8472, which allows real-time access to device operating parameters such as transceiver temperature, laser bias current, transmitted optical power, received optical power and transceiver supply voltage.
Key Features

●Supports 9.95 to 11.3 Gb/s bit rates
●Duplex LC connector
●Hot pluggable SFP+ footprint
●Cooled EML transmitter and PIN-TIA receiver
●Applicable for 40km SMF connection
●Low power consumption, < 1.2W
●100 GHz channel spacing
●Digital Diagnostic Monitor Interface
●Optical interface compliant to ITU-T 694.1& G.698.1
●Electrical interface compliant to SFF-8431& SFF-8432
●Operating case temperature:
Commerical:0 to 70 °C

Industrial:-5 to 80 °C

Applications

●10G Ethernet

●2x,4x, 8x Fiber Channel

●ITU-T G.698.1

●Other optical links
10G DWDM SFP+ Optical Transceiver Module with 40km Distance 100GHz Channel Spacing and CH17~61 Wavelength
10G DWDM SFP+ Optical Transceiver Module with 40km Distance 100GHz Channel Spacing and CH17~61 Wavelength
10G DWDM SFP+ Optical Transceiver Module with 40km Distance 100GHz Channel Spacing and CH17~61 Wavelength

Channel Selection:

Channel

Frequency (THz)

CenterWavelength (nm)

17

191.7

1563.86

18

191.8

1563.05

19

191.9

1562.23

20

192.0

1561.42

21

192.1

1560.61

22

192.2

1559.79

23

192.3

1558.98

24

192.4

1558.17

25

192.5

1557.36

26

192.6

1556.55

27

192.7

1555.75

28

192.8

1554.94

29

192.9

1554.13

30

193.0

1553.33

31

193.1

1552.52

32

193.2

1551.72

33

193.3

1550.92

34

193.4

1550.12

35

193.5

1549.32

36

193.6

1548.51

37

193.7

1547.72

38

193.8

1546.92

39

193.9

1546.12

40

194.0

1545.32

41

194.1

1544.53

42

194.2

1543.73

43

194.3

1542.94

44

194.4

1542.14

45

194.5

1541.35

46

194.6

1540.56

47

194.7

1539.77

48

194.8

1538.98

49

194.9

1538.19

50

195.0

1537.40

51

195.1

1536.61

52

195.2

1535.82

53

195.3

1535.04

54

195.4

1534.25

55

195.5

1533.47

56

195.6

1532.68

57

195.7

1531.90

58

195.8

1531.12

59

195.9

1530.33

60

196.0

1529.55

61

196.1

1528.77
