FC / UPC 12 Color Bundle Fiber Optic Patch Cord 0.9mm Single Mode Stable Capability
FC / UPC 12 Color Bundle Fiber Optic Patch Cord 0.9mm Single Mode Stable Capability
Specifications
Place of Origin :
shenzhen
Brand Name :
DYS/OEM
Certification :
IS09001-2015.ROHS
Model Number :
FC 12C-B-SM-0.9mm
Mode :
Single-mode or Multi-mode
Insert loss :
≤0.2dB
Suitcable fiber :
9/125μm,50/125μm,62.5/125μm
MOQ :
Negotiable
Packaging Details :
1pcs in 1 packign or Customized
Delivery Time :
2-5 days
Payment Terms :
T/T or L/C,Western Union,Paypal
Supply Ability :
500000PCS / Month
Price :
Negotiable
Description

FC / UPC 12 Color Bundle Fiber Optic Patch Cord 0.9mm Single Mode Stable Capability

Quick Details

Brand Name: DYS

Model Number: FC / UPC 12 Color

Mode: Singlemode

Insertion Loss≤0.5 dB

Repeatability≦0.1

Features
* Low insertion loss value
* High back reflection loss value
* Stable capability and high reliability
* Precis connector
* Excellent mechanical capability
* Boots in a variety of colors

Specifications

Item Single Mode Multi Mode
Insertion Loss ≦0.2dB ≦0.3bB
Return Loss PC≥50dB, UPC≥55dB, APC≥60dB
Insert-pull Test 1000 times
Repeatability ≦0.1
Tensile strength ≥10kg
Operating Temperature -40°C ~ +85°C
Ceramic Ferrule Specification 125.5um concentricity deviations: ≦1um 127um concentricity deviations: ≦3um
Suitable Fiber 9/125um 50/125um, 62.5/125um


Applications
* CATV
* Telecom network
* Optical test equipment
* Local area networks
* Wide area networks
* Data processing Networks
FC / UPC 12 Color Bundle Fiber Optic Patch Cord 0.9mm Single Mode Stable Capability

Competitive Advantage

DYS strictly enforce the ISO9001 quality management system, companies with good facilities and qualified human resources management to ensure product quality stability and excellent performance; and good after-sales service, to win the trust of customers, products exported to Europe and the United States and Southeast Asian countries.

Certificate of qualification

FC / UPC 12 Color Bundle Fiber Optic Patch Cord 0.9mm Single Mode Stable Capability
