1.25g SFP BIDI 40km LC DDM Module Transceiver
1.25g SFP BIDI 40km LC DDM Module Transceiver
1.25g SFP BIDI 40km LC DDM Module Transceiver
1.25g SFP BIDI 40km LC DDM Module Transceiver
1.25g SFP BIDI 40km LC DDM Module Transceiver
1.25g SFP BIDI 40km LC DDM Module Transceiver
1.25g SFP BIDI 40km LC DDM Module Transceiver
1.25g SFP BIDI 40km LC DDM Module Transceiver
Specifications
Brand Name :
YXFiber
Certification :
CE ROHS ISO9001
Place of Origin :
China
MOQ :
50 pairs
Price :
usd8.8-usd9.5/pairs
Payment Terms :
L/C, T/T
Supply Ability :
10000pcs/day
Delivery Time :
2-3 working days
Packaging Details :
anti-static plastic bag
DATA rate :
1.25g
fiber type :
single Fiber
wave length :
1310/1550
transmission distance :
40km
connector :
LC
Laser :
DFB/PIN
power supply :
3.3V
warranty :
3 year
Description

1.25g Bidi 40km 1310nm/1550nm LC Connector DDM DOM SMF SFP Module Transceiver

Technical Parameters Descriptions Technical Parameters Descriptions
Model Number YXF-GE-B35L-40D,
YXF-GE-B53L-40D		 Connector LC
Fiber type SMF Laser/Detector 1310nm: FP/PIN 1550nm:DFB/PIN
Form Factor BIDI SFP DDM Yes
Data Rate 1.25Gbps Output Power -5~0dBm
Wavelength Rx1310/Rx1550nm,
Tx1550nm/Rx1310nm		 Power Supply 3.3V
Distance 40KM Temperature 0~70°C
Sensitivity <-24.0dBm Certificate CE,ROHS,FCC,ISO9001,SGS
Selling Units 1 Pair Warranty 1Year

Features:

  1. SFP package with LC connector
  2. 1310nm FP Laser and 1550nm PIN photodetector
  3. 1550nm DFB Laser and 1310nm PIN photodetector
  4. Up to 20Km transmission on SMF
  5. +3.3V single power supply
  6. LVPECL compatible data input/output interface
  7. Low EMI and excellent ESD protection
  8. laser safety standard IEC-60825 compliant
  9. Compatible with RoHS
  10. Compatible with SFF8472

• WDM Fast Ethernet Links
• IEEE 802.3ah 1000BASE-BX Applications
• Fibre Channel Links.

Parameter Symbol Min Max Unit
Storage Temperature TSTG -40 +85 ºC
Ambient Operating Temperature TA 0 70 ºC
Optical Rise/Fall Time Tr /Tf - 0.26 ns
Eye Diagram IEEE 802.3z and ANSI Fibre Channel Compliant
Power Supply Current Icc - 200 mA
Extinction Ratio ER 9 13 dB
Sensitivity S - -24 dBm
Warning assert>-34dBm,de-assert<-26dBm

1.25g SFP BIDI 40km LC DDM Module Transceiver
