LC Tail Set Fiber Optic Cable Assembly Color Customized For CATV System
LC Tail Set Fiber Optic Cable Assembly Color Customized For CATV System
Specifications
Brand Name :
New Light
Certification :
CE,RoHS
Place of Origin :
China
MOQ :
100
Price :
0.1~100
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
100000 per week
Delivery Time :
7 working days
Packaging Details :
100 pcs per pack
Name :
LC tail set
Connector :
LC
Diameter :
2.0/3.0mm
Color :
Aqua or Customized
Mode :
SM/MM
OEM :
Available
Description

Fiber patch cord use LC tail set 2.0 / 3.0 mm diameter Aqua color

Description:

Optical fiber connectors, it is the two end precision optical fiber optic jumper,dock up according to the transmission medium can be divided into common silicon-based optical single-mode, multi-mode jumpers, and other such as plastic for transmission medium of fiber optic jumper cables,By connecting head structure forms can be divided into: FC jumper cables, SC jumpers, ST jumper cables, LC jumper cables,MTRJ jumper cables, MPO jumper cables, MU jumper cables, SMA jumper cables.

Features:


* Single mode and Multimode
* Zirconia sleeves or Phosphor bronze sleeves
* Available without flanges or with flange for duplex, saving panel space
* Meet JIS5974 and bellcore GR-326 standard
* Compliant with IEC874-14 & IEC874-19
* All parts compliant with ROHS
* Low insertion loss and back reflection loss
* Boots in a variety of colors
* 0.9/2.0/3.0mm boot

Application:

* Optical fiber communication system

* Optical fiber test equipment

* Optical fiber access network

* Optical fiber sensor

* Optical fiber CATV system

* Optical fiber data transmission

* Local area network

Specification:

Connector type SC
Standards IEC,RoHS
Color Customized
Mode SM/MM
Sleeve Ceramic/Phosphor Bronze

Parameter

Unit

 LC,SC,FC,ST,MTRJ,MOP
SM MM
PC UPC APC PC
Insertion Loss (Typical) dB ≤0.2 ≤0.2 ≤0.2 ≤0.2
Return Loss dB ≥45 ≥50 ≥60 ≥30
Exchangeability dB ≤0.2
Repeatability dB ≤0.2
Durability Time >1000
Operating temperature ℃ -40~75
Storage temperature ℃ -40~85

LC Tail Set Fiber Optic Cable Assembly Color Customized For CATV System
