Compatible Sfp Modules 1.25G BIDI SFP 120KM Tx1490nm Rx1550nm 1000base
Compatible Sfp Modules 1.25G BIDI SFP 120KM Tx1490nm Rx1550nm 1000base
Compatible Sfp Modules 1.25G BIDI SFP 120KM Tx1490nm Rx1550nm 1000base
Compatible Sfp Modules 1.25G BIDI SFP 120KM Tx1490nm Rx1550nm 1000base
Specifications
Brand Name :
Sourcelight or OEM
Model Number :
1.25g bidi sfp 120km
Certification :
CE/FCC/RoHS/TUV/UL
Place of Origin :
Shenzhen,China
MOQ :
1PCS
Price :
Get Latest Price
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
500PCS Per Week
Delivery Time :
Shipped in 1 days after PO confirmed
Packaging Details :
10PCS or 20PCS Plastic trays; 1pc gift box.
Datarate :
1.25G BIDI SFP 120KM
Wavelength :
TX1490NM/RX1550NM
Distance :
120KM
Transmitter :
DFB Laser
Receiver :
APD
Connector :
Simplex LC/UPC
Description

Compatible Sfp Modules 1.25G BIDI SFP 120KM Tx1490nm Rx1550nm 1000base

Overview

The SFP BIDI transceivers are high performance, cost effective modules supporting dual data-rate of 1.25Gbps/1.0625Gbps and 120km transmission distance with SMF.

The transceiver consists of three sections: a DFB laser transmitter, a APD photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.

The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472. For further information, please refer to SFP MSA.

Features

  • Dual data-rate of 1.25Gbps/1.063Gbps operation
  • 1490nm DFB laser and APD photodetector for 120km transmission
  • Compliant with SFP MSA and SFF-8472 with simplex LC receptacle
  • Digital Diagnostic Monitoring:
  • Internal Calibration or External Calibration
  • Compatible with RoHS
  • +3.3V single power supply
  • Operating case temperature:
  • Standard : 0 to +70°C

Parameter

Package (Form Factor) BIDI SFP
Data Rate (typical) 1.25 Gb/s
Centre Wavelength Tx1490nm/Rx1550nm
Distance 120km
Diagnostics Digital Monitor
Transmitter DFB Laser
Receiver APD photo detector
TX Output Power (dBm) 0~+5
RX Sensitivity (dBm) -30
Low/High Case Temperature 0°C~70°C
Voltage Supply (typical) 3.3v
Connector Simplex LC/UPC

Application
  • Gigabit Ethernet
  • Fiber Channel
  • Switch to Switch interface
  • Switched backplane applications
  • Router/Server interface
  • Other optical transmission systems

Compatible Sfp Modules 1.25G BIDI SFP 120KM Tx1490nm Rx1550nm 1000base

Competitive advantage
1. Excellent quality and 3 years warranty
2. Competitive pricing
3. Full compatible (HP/Extreme/Juniper/H3C…)
4. OEM/ODM Customized label
5. Keep stock,Fast delivery
