Optical Grade Borosilicate Glass Prismatic Lens for Specialty Lighting
Optical Grade Borosilicate Glass Prismatic Lens for Specialty Lighting
Optical Grade Borosilicate Glass Prismatic Lens for Specialty Lighting
Optical Grade Borosilicate Glass Prismatic Lens for Specialty Lighting
Optical Grade Borosilicate Glass Prismatic Lens for Specialty Lighting
Optical Grade Borosilicate Glass Prismatic Lens for Specialty Lighting
Specifications
Brand Name :
LONGWAY
Model Number :
OG0014528
Certification :
ISO9001
Place of Origin :
Shanghai, China
MOQ :
600 pieces
Price :
NEGOTIATION
Payment Terms :
T/T,Western Union
Supply Ability :
25000 Pieces per Month
Packaging Details :
paper,foam,carton
Structure :
Prismatic
Surface :
Optical grade
Transmission :
over 90%
Processing :
grinding and polishing
Application :
Optics and lighting
OEM :
available
Description



Optical Grade Borosilicate Glass Prismatic Lens for Specialty Lighting


1. Material

  • Core Substrate: Optical-grade borosilicate glass (e.g., Schott Borofloat® 33, Corning 7980) with exceptional purity (>99.9% SiO₂).

  • Key Additives: Boron trioxide for low thermal expansion, alkali oxides for chemical resistance.

  • Coatings: Optional AR/IR coatings for wavelength-specific transmission enhancement.


2. Key Properties

  • Optical Clarity: >92% transmission (400–700nm VIS range), minimal bubbles/inclusions (Class 0-1 per ISO 12123).

  • Thermal Resilience: Low CTE (3.25 × 10⁻⁶/K), withstands thermal shocks up to 160°C ΔT.

  • Surface Precision: λ/4 surface flatness, 80-50 scratch-dig standard.

  • Refractive Control: Precise refractive index (nd=1.47–1.51) for controlled light bending.

  • Durability: Resists acids, water, and UV degradation (unlike acrylic).


3. Primary Function

  • Light Redirection: Uses prismatic geometry to refract, reflect, or disperse light via total internal reflection (TIR).

  • Beam Shaping: Converts raw light into uniform patterns (e.g., flat-top, linear, or asymmetric distributions).

  • Glare Reduction: Minimizes hotspots by diffusing light angles.

  • Color Fidelity: Maintains CRI >95 with minimal chromatic shift.


4. Critical Applications

  • Architectural Lighting:

    • Cove lighting diffusers

    • Linear LED channel systems

    • Museum accent fixtures

  • Entertainment:

    • Stage/studio spotlight lenses

    • Projection system homogenizers

  • Commercial/Industrial:

    • Retail display case lighting

    • Machine vision inspection optics

    • Medical device illuminators (endoscopes, surgical lights)

  • Transportation:

    • Aircraft cabin mood lighting

    • Automotive signal lenses


Item Glass lens, Glass shade, Glass cover
Material Borosilicate glass
Diameter Tolerance +0/-0.5 mm
Thickness Tolerance +/-0.2 mm
Processed By Molding and Polishing
Working temperature Resisting high temperature shock
Surface Quality Clear and smooth
Transmission Around 90% for visible light
Tempering Available
Usage Lighting system and Optics etc.


Optical Grade Borosilicate Glass Prismatic Lens for Specialty Lighting


Optical Grade Borosilicate Glass Prismatic Lens for Specialty Lighting


Optical Grade Borosilicate Glass Prismatic Lens for Specialty Lighting
