ASK50 2200RPM Freewheel Roller Bearing One Way Clutch
ASK50 2200RPM Freewheel Roller Bearing One Way Clutch
ASK50 2200RPM Freewheel Roller Bearing One Way Clutch
ASK50 2200RPM Freewheel Roller Bearing One Way Clutch
ASK50 2200RPM Freewheel Roller Bearing One Way Clutch
ASK50 2200RPM Freewheel Roller Bearing One Way Clutch
ASK50 2200RPM Freewheel Roller Bearing One Way Clutch
ASK50 2200RPM Freewheel Roller Bearing One Way Clutch
Specifications
Brand Name :
SUMA
Model Number :
ASK50
Certification :
ISO SGS
Place of Origin :
CHINA
MOQ :
1
Price :
USD120-USD150 PER PIECE
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, Paypal
Supply Ability :
1000PCS Per Month
Delivery Time :
10-15 Days
Packaging Details :
Carton Box
Product Name :
One Way Clutch Bearing ASK50
Material :
GCr15 Bearing Steel
Torque Capacity :
125Nm
Unit Weight :
0.34Kg
Warranty :
1 Year
Size :
50*80*16mm
Rotation Speed :
2200RPM
OEM :
Accept
Description

ASK50 2200RPM Freewheel Roller Bearing One Way Clutch

Features

1. Type ASK is a roller type freewheel bearing supported by two rows of roller bearings.

2. The standard radial clearance is C4

3. Shaft tolerance should be h6 or j6

4. Type ASK freewheels can not accept axial loading. In cases of such loads, thrust bearings must be provided

Technical Datas

Model ASK50
Materail GCr15
Inner Diameter 50mm
Outer diameter 80mm
Thickness 16mm
Torque capacity 125Nm
Drag Torque 20Ncm
Max overrunning speed 2200r/min
Application Backstop, Overrunning
Package carton package / Wooden package
Delivery time 5-7 days
Payment terms TT, L/C, D/P, D/A, Western Union, Paypal

Dimensions and Capacities

Type Size Bearing Series TKN1) nmax Outside Diameter Height Bearing loads Weight Drag torque
Dynamic static
ASK Dp6
(mm)
(Nm)
(min-1)		 D
(mm)		 L
(mm)		 C
(kN)		 C0
(kN)		 (kg) TR
(Ncm)
40 6008 72 3500 68 15 16 20.6 0.25 15
50 6010 125 2200 80 16 19.6 23.5 0.34 20
60 6012 250 1800 95 18 25.3 35.1 0.5 25

NOTES
1) Tmax = 2 × TKN
» Refer to Selection page 10 to 13
» Refer to mounting and maintenance instructions page 16 to 19

Mounting Example

Pictures

ASK50 2200RPM Freewheel Roller Bearing One Way Clutch

ASK50 2200RPM Freewheel Roller Bearing One Way Clutch
ASK50 2200RPM Freewheel Roller Bearing One Way Clutch
