HuaWei EG8145A5 GPON ONT ONU ONT FTTH Optical Fiber Cat
HuaWei EG8145A5 GPON ONT ONU ONT FTTH Optical Fiber Cat
HuaWei EG8145A5 GPON ONT ONU ONT FTTH Optical Fiber Cat
HuaWei EG8145A5 GPON ONT ONU ONT FTTH Optical Fiber Cat
Specifications
Brand Name :
HuaWei
Model Number :
EG8145A5
Place of Origin :
China, Guangdong
MOQ :
Negotiable
Price :
Negotiable
Products Name :
GPON ONU
Product model :
EG8145A5
Ports :
1 POTS + 1 GE + 3 FE + 2.4G Wi-Fi
Static Power Consumption :
3.1W
Dimensions (H × W × D) :
30 mm x 152 mm x 105 mm
Weight :
< 180 g
Maximum power consumption :
7.15W
Power Adapter Input :
11V to 14V DC, 1.5A
Description

HuaWei EG8145A5 GPON ONT ONU ONT FTTH Optical Fiber Cat

HuaWei GPON ONU ONT EG8145A5 1GE+3FE+1TEL+USB +WIFI Router English firmware FTTH optical fiber cat

EchoLife EG8141A5 descriptions

The EchoLife EG8141A5 provides one GE port, one POTS port, three FE ports and supports 2.4G Wi-Fi. The ONT features high-performance forwarding capabilities to ensure excellent experiences with VoIP, Internet, and HD video services. These features make the EG8141A5 a perfect choice for broadband access.

EchoLife EG8141A5 Specifications

Model EG8141A5
Dimensions (L x W x H) 30 mm x 152 mm x 105 mm
(without external antenna and pads)
Weight < 180 g
Operating Temperature 0°C to +40°C
Operating Humidity 5% RH to 95% RH (non-condensing)
Power Adapter Input 100V to 240V AC, 50/60 Hz
System Power Supply 11V to 14V DC, 1.5A
Static Power Consumption 3.1W
Maximum Power Consumption 7.15W
NNI GPON
UNI 1 POTS + 1 GE + 3 FE + 2.4G Wi-Fi
Optical Connector SC/APC
Indicators POWER/PON/LOS/LAN/TEL/WLAN/WPS

HuaWei EG8145A5 GPON ONT ONU ONT FTTH Optical Fiber CatHuaWei EG8145A5 GPON ONT ONU ONT FTTH Optical Fiber Cat

HuaWei EG8145A5 GPON ONT ONU ONT FTTH Optical Fiber Cat

Application and Advantage:
1.Full compatible with ITU-T G.984.
2.Support port-based rate limitation and bandwidth control
3.Integrated OMCI remote configuration and maintenance function.
4.Support data enscryption, group broadcasting, port Vlan separation ,RSTP,etc.
5.Support Dynamic Bandwidth Allocation (DBA)
6.Support ONT auto-discovery/Link detection/remote upgrade of software;
7.Support VLAN division and user separation to avoid broadcast storm;
8.Support power-off alarm function ,easy for link problem detection
9.Support broadcasting storm resistance function
10.Support port isolation between different ports
11.Support ACL and SNMP to configure data packet filter flexibly
12.Specialized design for system breakdown prevention to maintain stable system
13.Support software online upgrading
14.EMS network management based on SNMP ,convenient for maintenance

FAQ

1. what's the way to pay?

We support T/T, WESTERN UNION,Paypal

2.What's your shipping way?

Shopped by air sea express

3.What is the product used for packing?

We always use catron, Unless you have different packing needs

With many years of export experience, excellent quality, advanced services and competitive prices, it has won the trust and support of many customers. If you have any questions, please feel free to contact us, we will provide you with quality service.
