Specifications
Products Status :
Stock
Ports :
24, >= 48
Transmission Rate :
10/100/1000Mbps
Function :
LACP, QoS, SNMP, Stackable, VLAN Support
Communication Mode :
Full-Duplex & Half-Duplex
Certification :
ce, CCC
Switch Capacity :
2.56 Tbit/s
Brand Name :
HuaWei
Model Number :
S6720-30L-HI-24S, S6720-30L-HI-24S
Place of Origin :
Guangdong, China
Forwarding Perforance :
420 Mpps
Extended Slots :
Not supported
VLAN Features :
4K VLANs Guest VLANs and voice VLANs GVRP MUX VLAN
Interoperability :
VLAN-based Spanning Tree (VBST) - interoperating with PVST, PVST+
Rated AC voltage :
100 V to 240 V AC; 50/60 Hz
Fixed Ports :
24 x 10-Gigabit SFP+, 4 x 40-Gigabit QSFP+, and 2 x 100-Gigabi
MAC Address Table :
64K MAC address entries IEEE 802.1d standards compliance
IP Routing :
Static routes, RIP v1/2, RIPng, OSPF, OSPFv3, IS-IS, IS-ISv6, BGP
Selling Units :
Single item
Single package size  :
57X5X32 cm
Single gross weight :
3.000 kg
Package Type :
new in the box.
MOQ :
Negotiable
Price :
Negotiable
Description

Huawei S6720-HI Series Agile 10 GE Switches S6720-30L-HI-24S fixed agile switches

Product Description

Huawei S6720-HI series 10 GE switches are fixed agile switches with 10 GE downlink and 40 GE/100 GE uplink ports, that are applicable to enterprise campus, carrier, university, and government networks.

The S6720-HI delivers abundant agility features and uses a fully programmable architecture to implement software-defined functions and on-demand service changes. With services and network convergence as the core, the S6720-HI supports native AC function to manage APs. In addition, the switch provides free mobility features, to ensure consistent user experience, and features Super Virtual Fabric (SVF) to virtualize the entire network into one device.

Pictures

Original Huawei 02351mxr agile 10GE switch S6720-30L-HI-24S fixed agile switches

Original Huawei 02351mxr agile 10GE switch S6720-30L-HI-24S fixed agile switches

Specifications¹

Product Model S6720-50L-HI-48S S6720-30L-HI-24S
Switching Capacity 2.56 Tbit/s 2.56 Tbit/s
Fixed Ports 48 x 10 Gigabit SFP+, 6 x 40 Gigabit QSFP+ or 44 x 10 Gigabit SFP+, 4 x 40 Gigabit QSFP+, and 2 x 100 Gigabit QSFP28 24 x 10 Gigabit SFP+, 4 x 40 Gigabit QSFP+, and 2 x 100 Gigabit QSFP28
Extended Slots Not supported Not supported
MAC Address Table 64K MAC address entries
IEEE 802.1d standards compliance
MAC address learning and aging
Static, dynamic, and blackhole MAC address entries
Packet filtering based on source MAC addresses
VLAN Features 4K VLANs
Guest VLANs and voice VLANs
GVRP
MUX VLAN
VLAN assignment based on MAC addresses, protocols, IP subnets, policies, and ports
VLAN mapping
IP Routing Static routes, RIP v1/2, RIPng, OSPF, OSPFv3, IS-IS, IS-ISv6, BGP, BGP4+, ECMP, and routing policy
Interoperability VLAN-Based Spanning Tree (VBST) (interoperating with PVST, PVST+, and RPVST)
Link-type Negotiation Protocol (LNP) (similar to DTP)
VLAN Central Management Protocol (VCMP) (similar to VTP)
For detailed interoperability certifications and test reports, click HERE.
Specification

Product Model S6720-50L-HI-48S S6720-30L-HI-24S
Switching Capacity 2.56 Tbit/s 2.56 Tbit/s
Forwarding Performance 420 Mpps 420 Mpps
Fixed Ports 48 x 10-Gigabit SFP+ and 6 x 40-Gigabit QSFP+ or 44 x 10-Gigabit SFP+, 4 x 40-Gigabit QSFP+, and 2 x 100-Gigabit QSFP28 24 x 10-Gigabit SFP+, 4 x 40-Gigabit QSFP+, and 2 x 100-Gigabit QSFP28
Extended Slots Not supported Not supported
MAC Address Table 64K MAC address entries
IEEE 802.1d standards compliance
MAC address learning and aging
Static, dynamic, and Blackhole MAC address entries
Packet filtering based on source MAC addresses
VLAN Features 4K VLANs
Guest VLANs and voice VLANs
GVRP
MUX VLAN
VLAN assignment based on MAC addresses, protocols, IP subnets, policies, and ports
VLAN mapping
IP Routing Static routes, RIP v1/2, RIPng, OSPF, OSPFv3, IS-IS, IS-ISv6, BGP, BGP4+, ECMP, and routing policy
Interoperability VLAN-based Spanning Tree (VBST) — interoperating with PVST, PVST+, and RPVST
Link-type Negotiation Protocol (LNP) — similar to DTP
VLAN Central Management Protocol (VCMP) — similar to VTP
For detailed interoperability certifications and test reports, click HERE.
