4 Port Huawei GPON HG8546M Antenna ONU For FTTH
4 Port Huawei GPON HG8546M Antenna ONU For FTTH
4 Port Huawei GPON HG8546M Antenna ONU For FTTH
4 Port Huawei GPON HG8546M Antenna ONU For FTTH
4 Port Huawei GPON HG8546M Antenna ONU For FTTH
4 Port Huawei GPON HG8546M Antenna ONU For FTTH
4 Port Huawei GPON HG8546M Antenna ONU For FTTH
4 Port Huawei GPON HG8546M Antenna ONU For FTTH
4 Port Huawei GPON HG8546M Antenna ONU For FTTH
4 Port Huawei GPON HG8546M Antenna ONU For FTTH
Specifications
Place of Origin :
Guangdong, China
Brand Name :
Huawei
Model Number :
HG8546M
MOQ :
Negotiable
Price :
Negotiable
Type :
Gpon
Brand :
huawei
Product name :
HG8546M
port :
4
L/T :
3 DAYS
Selling Units :
Single item
Single package size  :
25X15X5 cm
Single gross weight :
1.000 kg
Package Type :
NEW IN THE BOX
Description

4 Port Huawei GPON HG8546M Antenna ONU

The EchoLife HG8546M, an optical network terminal (ONU), is a high-end home gateway in Huawei FTTH solution. By using the GPONtechnology, ultra-broadband access is provided for home and SOHO users.

The H8546M provides 1* POTS ports, 4* FE auto-adapting Ethernet ports, and 1* Wi-Fi port. The H8546M features high-performance forwarding capabilities to ensure excellent experience with VoIP, Internet and HD video services.

Therefore, the H8546M provides a perfect terminal solution and future oriented service supporting capabilities for FTTH deployment.

Huawei GPON ONU HG8546M Product Specifications
* Dimensions(W x D x H):250 mm x 185 mm x 35 mm
* Port:1POTS+4FE+1USB+1Wi-Fi
* Average power consumption:8 W
* Operating environment:Temperature: 0℃～+40℃;
* Humidity: 5%–95%, non-condensing*Power supply:Adapter input: 100–240 V AC, 50–60Hz;
* Adapter output: 11–14 V DC, 1 A*Weight:About 500g (including the power adapter)
Huawei EchoLife HG8546M
Model HG8546M
Out Port Contains 1GE+3FE+1TEL+1USB+WiFi
Quality 100% New
USB USB2.0
Firmware English
Weight <450g
Wavelength Tx 1310nm, Rx 1490nm
Fiber Interfare SC/FC-UPC/APC Dual mode/Singal mode
RX sensitivity >-28dBm(1490nm)
Machine Power 12V 1.0A
Button Power
Working temperature -10°C~+45°C
working humidity 5%-95%(non-condensation)
4 Port Huawei GPON HG8546M Antenna ONU For FTTH
