1.25G Gigabit Single Mode Optical Module 1310nm 40km LC H3C SFP-GE-LH40-SM1310-D
1.25G Gigabit Single Mode Optical Module 1310nm 40km LC H3C SFP-GE-LH40-SM1310-D
1.25G Gigabit Single Mode Optical Module 1310nm 40km LC H3C SFP-GE-LH40-SM1310-D
1.25G Gigabit Single Mode Optical Module 1310nm 40km LC H3C SFP-GE-LH40-SM1310-D
Specifications
Brand Name :
H3C
Model Number :
SFP-GE-LH40-SM1310-D
Place of Origin :
China
MOQ :
Negotiable
Price :
Negotiable
Supply Ability :
10000
Delivery Time :
3-5DAYS
Packaging Details :
NEW IN THE BOX.
Model name :
SFP-GE-LH40-SM1310-D
Name :
SFP 40km single fiber optical module
Connector :
LC Connector
Wavelength :
1310nm
Date rate :
1.25G
Warranty :
1 Year
Description

1.25G Gigabit Single Mode Optical Module 1310nm 40km LC H3C SFP-GE-LH40-SM1310-D

Overviews

SFP-GE-LH40-SM1310-D 1.25G SFP LX 1310nm 40km

Model No.: BT-OC24-40 1.25Gbps SFP Optical Transceiver,1310nm 40km Reach

The SFP transceivers are high performance, cost effective modules supporting data-rate of 1.25Gbps and 40km transmission distance with SMF.
The transceiver consists of three sections: a DFB laser transmitter, a PIN photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.
The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472. For further information, please refer to SFP MSA.

Product Type SFP fiber optic module
Product Overview Optical Module-SFP-GE-Single Mode Module-(1310nm,40km,LC)

Features

1. Data-rate of 1.25Gbps operation
2. 1310nm DFB laser and PIN photodetector for 40km transmission
3. Compliant with SFP MSA and SFF-8472 with duplex LC receptacle
4. Digital Diagnostic Monitoring:
Internal Calibration or External Calibration
5. Compatible with SONET OC-24-LR-1
6. Compatible with RoHS
7. +3.3V single power supply
8. Operating case temperature:
Standard : 0 to +70°C
Extended : -20 to +85°C

Applications

1. Gigabit Ethernet
2. Fiber Channel
3. Switch to Switch interface
4. Switched back plane applications
5. Router/Server interface
6. Other optical transmission systems

1.25G Gigabit Single Mode Optical Module 1310nm 40km LC H3C SFP-GE-LH40-SM1310-D

Ordering Information

SFP

GLC-SX-MM

1000BASE-SX SFP transceiver module, MMF, 850nm

GLC-SX-MMD

1000BASE-SX SFP transceiver module, MMF, 850nm, DOM

GLC-LH-SM

1000BASE-LX/LH SFP transceiver module, MMF/SMF, 1310nm

GLC-LH-SMD

1000BASE-LX/LH SFP transceiver module, MMF/SMF, 1310nm, DOM

GLC-EX-SM

1000BASE-EX SFP transceiver module, SMF, 1310nm

GLC-EX-SMD

1000BASE-EX SFP transceiver module, SMF, 1310nm, DOM

GLC-ZX-SM

1000BASE-ZX SFP transceiver module, SMF, 1550nm

GLC-ZX-SMD

1000BASE-ZX SFP transceiver module, SMF, 1550nm, DOM

GLC-T

1000BASE-T SFP transceiver module

GLC-TE

1000BASE-T SFP transceiver module, Extended Temperature

SFP+

SFP-10G-SR

10GBASE-SR SFP+ transceiver module for MMF, 850nm

SFP-10G-SR-S

10GBASE-SR SFP+ transceiver module for MMF, 850nm, S-Class

SFP-10G-SR-X

10GBASE-SR SFP+ transceiver module for MMF, 850nm, Extended Temperature

SFP-10G-LR

10GBASE-LR SFP+ transceiver module for SMF, 1310nm

SFP-10G-LR-S

10GBASE-LR SFP+ transceiver module for SMF, 1310nm, S-Class

SFP-10G-LR-X

10GBASE-LR SFP+ transceiver module for SMF, 1310nm, Extended Temperature

SFP-10G-LRM

10GBASE-LRM SFP+ transceiver module for MMF and SMF, 1310nm

SFP-10G-ER

10GBASE-ER SFP+ transceiver module for SMF, 1550nm

SFP-10G-ER-S

10GBASE-ER SFP+ transceiver module for SMF, 1550nm, S-Class

SFP-10G-ZR

10GBASE-ER SFP+ transceiver module for SMF, 1550nm

SFP-10G-ZR-S

10GBASE-ER SFP+ transceiver module for SMF, 1550nm, S-Class

SFP-H10GB-CU1M

1-m 10G SFP+ Twinax cable assembly, passive

SFP-H10GB-CU1-5M

1.5-m 10G SFP+ Twinax cable assembly, passive

SFP-H10GB-CU2M

2-m 10G SFP+ Twinax cable assembly, passive

SFP-H10GB-CU2-5M

2.5-m 10G SFP+ Twinax cable assembly, passive

SFP-H10GB-CU3M

3-m 10G SFP+ Twinax cable assembly, passive

SFP-H10GB-CU5M

5-m 10G SFP+ Twinax cable assembly, passive

SFP-H10GB-ACU7M

7-m 10G SFP+ Twinax cable assembly, active

SFP-H10GB-ACU10M

10-m 10G SFP+ Twinax cable assembly, active

SFP-10G-AOC1M

10GBASE-AOC SFP+ Cable 1 Meter

SFP-10G-AOC2M

10GBASE-AOC SFP+ Cable 2 Meter

SFP-10G-AOC3M

10GBASE-AOC SFP+ Cable 3 Meter

SFP-10G-AOC5M

10GBASE-AOC SFP+ Cable 5 Meter

SFP-10G-AOC7M

10GBASE-AOC SFP+ Cable 7 Meter

SFP-10G-AOC10M

10GBASE-AOC SFP+ Cable 10 Meter

XFP

XFP-10G-MM-SR

10GBASE-SR XFP Module for MMF

XFP-10GLR-OC192SR

Multirate 10GBASE-LR/-LW and OC-192/STM-64 SR-1 XFP Module for SMF

XFP10GLR-192SR-L

Multirate 10GBASE-LR/-LW and OC-192/STM-64 SR-1 XFP Module for SMF, low power (1.5W)

XFP-10GER-OC192IR

10GBASE-ER and OC192IR2 XFP Module

XFP-10GER-192IR+

Multirate 10GBASE-ER/-EW and OC-192/STM-64 IR-2 XFP Module for SMF

XFP10GER-192IR-L

Multirate 10GBASE-ER/-EW and OC-192/STM-64 IR-2 XFP Module for SMF, low power (2.5W)

XFP-10GZR-OC192LR

Multirate 10GBASE-ZR/-ZW and OC-192/STM-64 lR-2 XFP Module for SMF

X2

X2-10GB-SR

10GBASE-SR X2 transceiver module for MMF, 850nm

X2-10GB-LR

10GBASE-LR X2 transceiver module for SMF, 1310nm

X2-10GB-LRM

10GBASE-LRM X2 transceiver module for MMF, 1310nm

X2-10GB-ER

10GBASE-ER X2 transceiver module for SMF, 1550nm

X2-10GB-ZR

10GBASE-ZR X2 transceiver module for SMF, 1550nm

XENPAK

XENPAK-10GB-SR

10GBASE-SR XENPAK transceiver module for MMF, 850nm

XENPAK-10GB-LR

10GBASE-LR XENPAK transceiver module for SMF, 1310nm

XENPAK-10GB-LR+

10GBASE-LR XENPAK transceiver module for SMF, 1310nm, DOM

XENPAK-10GB-LRM

10GBASE-LRM XENPAK transceiver module for MMF, 1310nm

XENPAK-10GB-ER

10GBASE-ER XENPAK transceiver module for SMF, 1550nm

XENPAK-10GB-ER+

10GBASE-ER XENPAK transceiver module for SMF, 1550nm, DOM

XENPAK-10GB-ZR

10GBASE-ZR XENPAK transceiver module for SMF, 1550nm

XENPAK-10GB-LX4

10GBASE-LX4 XENPAK transceiver module for MMF, 1310nm

FAQ

Q1. Can I order samples? What is your minimum order quantity?

A1: Yes, we welcome sample orders to test and check the quality.

Mixed samples are acceptable, our MOQ is one.

Q2. What are trade terms?

A2: Delivery time: usually 1-3 days, some special products are 5-8 days

Payment methods: wire transfer, Western Union, PayPal, escrow

Transportation: DHL, FedEx, UPS and air or sea

Q3. What about the warranty?

A3: Most new component sales provide a one-year warranty.

Q4. How do you control the quality?

A4: We have a complete QC system (IQC, IPQC, FQC, OQC team), professional product engineers and continuous improvement system.

Q5. Why choose us?

A5: Professional and experienced R&D team Reliable and strict quality control system Competitive price and best service
