Insulating Oil Breakdown Voltage Meter Dielectric Strength Testing Equipment

APPLICATION

IIJ-II Series Transformer Oil Dielectric Strength Tester is specially designed for testing dielectric strength
(Breakdown Voltage) of transformer oil.


In the electric power system, the insulation oil is widely applied in many insulation electric equipment. The breakdown voltage (dielectric strength) is one of the most important parameters, it is a rule of the voltage withstand. The value of breakdown voltage (dielectric strength) indicates whether the oil contains water, impurity and electric particles, and you'll know the oil value via the breakdown voltage (dielectric strength).


IIJ-II Series Transformer Oil Dielectric Strength Tester provides repeatable, accurate measurement of breakdown voltage of insulating oils used in electrical equipment. These versatile, light weight units have been designed for both field and laboratory use.

IIJ-II Series Transformer Oil Dielectric Strength Tester is designed as per the standard of IEC156 dielectric strength of insulating oil.This product adopt industrial single-chip control system, large-scale integrated circuit, new-style I/O interface, with unique inspection and anti-jamming technique, which greatly improve the equipment performance and reliability.

FEATURES

1. Simple operation, automatically (can be finished just press on key).
2. Menu controlled. Input data is clear.
3. Can store 99 groups of oil testing data, which is convenient to reading and print. The testing data can keep 100 years under the condition of power off.
4. System time can go on running under power off; (The system time is just for reference which can not be the standard of timing).
5. High capacity of anti-jamming, high precision of testing.
6. Small volume, light, which can be operated in the open air very conveniently.

TECHNICAL DATA

1. Power supply: AC220V ± 10%, 50HZ
2. Output voltage: 80KV, 100KV
3. Capacity: 1.6KVA, 2.0KVA
4. Pressure increase speed :about 2KV/S
5. Pressure testing speed: 3%
6. Dielectric strength sensitivity : <2KV
7. Wave form distortion : ≤3%
8. Time of dielectric strength: ≤10ms
9. Polar distance: 2.5mm
10. Operational environment: Temperature:0ºC-40ºC, Humidity: the most relative humidity 85%
11. Storage environment : Temperature:-20ºC-60ºC, Humidity: the most relative humidity 75%.
12. Working altitude: <1500m (if over 1500m can be designed specially)
13. Packing: Wooden Case
