Specifications
Ignition Type :
CDI
Engine Type :
Single cylinder, water cooling, four-stroke
MOQ :
40HQ Container
Displacement :
223cc
Front Braking :
Disc brakes
Start System :
Electric kick starter
Rear Braking :
Disc brakes
Brand Name :
OEM
Model Number :
YH250GY-K
Place of Origin :
Chongqing, China
MOQ :
40HQ
Price :
Negotiable
Payment Terms :
T/T
Delivery Time :
45 work days
Packaging Details :
SKD 108PCS/40HQ，CKD 155PCS/40HQ
Max. Power :
12/7500(kW/r/min)
Engine :
NC250
Supply Ability :
Customized
Max. Torquev :
18/5500(N·m/r/min)
Description

Description:

NC250 single cylinder, four-stroke, inclined, water-cooled, four-valve electric/foot start, water- cooled engine, competition board track carburetor, maintenance-free battery, track-style front and rear shock absorbers, with high-function cradle. Multi-function digital instrument, front and rear aluminum alloy lightweight mesh wheels, front wheel specifications 3.00-21, rear 4.60-18 deep tooth off-road tires, reinforced track board aluminum alloy flat fork, classic racing rearview mirror.

Specifications:

Item

Parameter

Dimensions (Length x Width x Height)

2165×805×1225

Seat Height

870mm

Wheelbase

1440mm

Minimum Ground Clearance

300mm

Maximum Load

150kg

Steering Angle

35

Side Stand Tilt Angle

14

Ride Capacity

1 Person

Dry Weight

110kg

Fuel Tank Capacity

7L

Front Braking System

Disc brakes

Rear Braking System

Disc brakes

Front Tire Size

80/100-21 4PR

Rear Tire Size

110/100-18 4PR

Battery Size

12V/6.5Ah

Engine Type

Single cylinder, water cooling, four-stroke

Engine displacement

223

Bore x stroke

69×62.2

Compression ratio

9.25:1

Maximum power

12/7500(kW/r/min)

Maximum torque

18/5500(N·m/r/min)

Maximum speed

95km/h

Start-up acceleration

14S

Overtaking acceleration

13S

Lubrication method

Pressure, Splash

Oil volume

1.5L

Clutch type

Multi-plate wet clutch, manual

Ignition method

CDI

Spark plug

A8RTC

Starting method

Electric kick starter

Transmission method

Chain drive

Final gear ratio

15:46

YH250GY-K

YH250GY-K

YH250GY-K

YH250GY-K

Frequently Asked Questions:

Q1. About us:

A: Jiangmen Songfeng Import and Export Co., Ltd. is the export arm of our manufacturing facility, Yuanhua Technology Co., Ltd. We provide factory-direct pricing and strict quality control, ensuring you receive competitive products straight from the source.

Q2. Payment Terms:

A: We require 30% deposit to begin production preparation, with the remaining 70% due upon completion before loading.

Q3. Delivery Timeline:

A: Depending on the order quantity, usually around 45 working days

Q4. Customization:

A: We can meet OEM requirements and, with the customer's authorization, use the customer's brand. Displacement and other configurations can be modified upon request.

Q5. After-sales Service:

A: We provide 24-hour online support to resolve quality issues at any time and guarantee the supply of all original spare parts to ensure your worry-free after-sales experience.
