Raspberry Pi Camera Module with IMX482 Sensor 640x488 Resolution
Raspberry Pi Camera Module with IMX482 Sensor 640x488 Resolution
Raspberry Pi Camera Module with IMX482 Sensor 640x488 Resolution
Raspberry Pi Camera Module with IMX482 Sensor 640x488 Resolution
Raspberry Pi Camera Module with IMX482 Sensor 640x488 Resolution
Raspberry Pi Camera Module with IMX482 Sensor 640x488 Resolution
Raspberry Pi Camera Module with IMX482 Sensor 640x488 Resolution
Raspberry Pi Camera Module with IMX482 Sensor 640x488 Resolution
Specifications
Brand Name :
Sinoseen
Model Number :
SNS21853-V1.0
Certification :
RoHS、ISO9001、CE
Place of Origin :
China
MOQ :
5
Price :
10-100usd or negotiable
Payment Terms :
T/T
Supply Ability :
500000 pieces/month
Delivery Time :
2-3week
Packaging Details :
Tray+Anti-static bag in carton box
Type: :
Raspberry PI Camera Module
Sensor: :
IMX482
Resolution: :
640H x 488V
Dimensions: :
38mmx38mm (compatible With 32mmx32mm)
Description

camera module Product Overview
The SNS-21853-V1.0 is a high-performance face recognition camera module built for demanding environments such as access control, smart monitoring, and AI-powered analytics. Powered by the SONY IMX482 sensor and HiSilicon Hi3516DV300 DSP, it produces lifelike 4MP images with wide dynamic range and low-light excellence.


Its AI features detect, track, and capture up to 32 faces in real time, while advanced H.265+ compression and ROI optimization keep data storage efficient. With day/night switching, intelligent control, and multi-platform compatibility, it’s the ideal solution for next-gen security systems.


camera module Key Highlights

  • Real-Time AI Face Recognition – Reliable in all light conditions

  • WDR + 3DNR – Handles complex lighting effortlessly

  • High Efficiency – H.265+ ROI encoding reduces storage costs

  • Flexible Integration – Compact PCB sizes and platform support

Customization Services Available
Tailored hardware and software adjustments for sensor, lens, and encoding formats to match your exact requirements.


About Sinoseen
We deliver camera modules from design to manufacturing, supporting industries like security, robotics, and industrial vision.

camera
Sensor Type 1/1.8 inch progressive scan CMOS 4 megapixels SC4210
HiSilicon Digital Signal Processor Hi3516DV300
Electronic shutter 1/12s ~ 1/8000s
Minimum Illumination Color 0.005lux F1.7;
B/W 0.001Lux F1.7;
Signal-to-Noise Ratio ≥ 50dB (AGC off)
Day and night mode Photosensitive detection/video detection/time detection
WDR ≥ 120dB
3DNR 3DNR
Demobilization and reintegration program 8Gb DDR
flash 128Mb SPI NAND Flash
Compression Standards
Video compression standards H.265 +/H.265/H.264/MJPEG
H.265 Main outline
Video bitrate 32 Kbps ~ 16Mbps
Audio compression format G.711a/ G.711u/G.726
Image Settings Brightness, contrast, saturation, sharpness, AWB, AGC, AE, AIC, privacy mask; OSD
Maximum image size 2560 × 1440
Video resolution Mainstream 1440P(2560 × 1440)/1920 × 1080
Child D1(704 × 576)/VGA(640 × 480)/640 × 352/QVGA(320 × 240)
Video frame rate 50Hz: 25fps
60Hz: 30fps
Character Overlay support
Smart Features
Smart Coding Supports low bit rate, low latency, ROI enhancement encoding of the region of interest, and supports 4 ROI areas
Intelligent Detection Supports occlusion detection, out-of-focus detection, brightness detection, color detection, sound detection, remaining detection, motion detection, virtual cordon, and area intrusion
Intelligent Control Supports intelligent control of alarm on, alarm off, fault clearing, and intelligent noise reduction
