SC3336 MIPI Camera Module 3MP 2304x1296 30fps Low-Light
SC3336 MIPI Camera Module 3MP 2304x1296 30fps Low-Light
SC3336 MIPI Camera Module 3MP 2304x1296 30fps Low-Light
SC3336 MIPI Camera Module 3MP 2304x1296 30fps Low-Light
SC3336 MIPI Camera Module 3MP 2304x1296 30fps Low-Light
SC3336 MIPI Camera Module 3MP 2304x1296 30fps Low-Light
SC3336 MIPI Camera Module 3MP 2304x1296 30fps Low-Light
SC3336 MIPI Camera Module 3MP 2304x1296 30fps Low-Light
SC3336 MIPI Camera Module 3MP 2304x1296 30fps Low-Light
SC3336 MIPI Camera Module 3MP 2304x1296 30fps Low-Light
Specifications
Brand Name :
Sinoseen
Model Number :
SNS32182-V1.0
Certification :
RoHS、ISO9001、CE
Place of Origin :
China
MOQ :
5
Price :
10-100USD or negotiable
Payment Terms :
T/T
Supply Ability :
500000 pieces/month
Delivery Time :
2-3week
Packaging Details :
Tray+Anti-static bag in carton box
Type: :
MIPI Camera Module
Sensor :
SC3336
Resolution :
2304 × 1296
Dimensions :
(compatible With 32mmx32mm)
High Light :
mipi Camera Module , Machine Vision SC3336 Camera Module
Description

Product Detail

The SC3336 3MP MIPI camera module (SNS32182-V1.0) is designed to deliver clear, detailed imaging in compact devices. Built around a 1/2.8" CMOS sensor with a 2.45µm pixel size, it supports 2304×1296 resolution at 30fps with excellent 78 dB dynamic range and 38 dB SNR, ensuring sharp images even in complex lighting.


With its 130° wide-angle lens (optional) and strong low-light sensitivity (5053 mV/Lux·s), this module is well-suited for applications like smart home monitoring, facial recognition, drones, video doorbells, dashcams, and action cameras. The standard MIPI interface ensures easy integration with popular platforms including RK, Qualcomm, MTK, and HiSilicon.


If you need a compact, high-quality, and reliable camera solution for imaging projects, the SC3336 module is a strong choice.


camera module Specification


Parameter Specification
Sensor Model SC3336
Resolution 3MP (2304 × 1296 @ 30fps)
Pixel Array 2312 × 1304
Pixel Size 2.45 µm × 2.45 µm
Optical Size 1/2.8"
Output Format RAW RGB, 10/8-bit
Output Interface 1/2 Lane MIPI
Dynamic Range 78 dB
SNR 38 dB
Sensitivity 5053 mV/Lux·s
Shutter Type Rolling Shutter
CRA 15°
IR Filter 650 nm
Operating Temp -30°C ~ +85°C
Optimal Temp -20°C ~ +60°C
Package CSP, 6.199 mm × 4.139 mm, 35-pin
Power Supply AVDD 2.8V ±0.1V, DOVDD 1.8V ±0.1V (DVDD built-in LDO)
Module Model SNS32182-V1.0
Focus Type Fixed Focus
Field of View 130° (optional)
Module Size 75 × 8.5 mm
Applications Smart home, digital signage, facial recognition, video doorbells, drones, toy cameras, dashcams, action cameras, document scanners
Supported Platforms RK, Qualcomm, Allwinner, MTK, Spreadtrum, HiSilicon, MStar
