Automatic 1.1m Cotton Fibre Opening Machine For Wadding Making
Automatic 1.1m Cotton Fibre Opening Machine For Wadding Making
Automatic 1.1m Cotton Fibre Opening Machine For Wadding Making
Automatic 1.1m Cotton Fibre Opening Machine For Wadding Making
Automatic 1.1m Cotton Fibre Opening Machine For Wadding Making
Automatic 1.1m Cotton Fibre Opening Machine For Wadding Making
Automatic 1.1m Cotton Fibre Opening Machine For Wadding Making
Automatic 1.1m Cotton Fibre Opening Machine For Wadding Making
Specifications
Brand Name :
HONGE
Model Number :
HYYS-150
Certification :
ISO9001/CE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T, L/C
Supply Ability :
2 set per month
Delivery Time :
10 working days after received your payment
Packaging Details :
Wooden package or PET film or naked
Product Name :
Opening machine/Pre-opner
Working Width :
Max. 1500mm
Capacity :
Max. 250kg/h/set
Raw Material :
PET,PP,low melt fiber,waste fiber .etc
Conveying Belt Speed :
≤12m/min
Detail :
Equipped with strong magnet
Conveying Belt Length :
According to amount of bale opener
Advantage :
modular design，easy installation
Description

ISO9001 Nonwoven automatic carbon fiber opener bale opening machine polyester fiber opening machine

Automatic 1.1m Cotton Fibre Opening Machine For Wadding Making

Function and characteristics of Bale opener

Open and blend the fibers prior to the next processes

There are several options for the opener depended on the fibers to be used

These options are :1.toothed, 2.pin plate opener or3. Wired opener

A plate magnet is included for metal extraction. Alarm and reverse running when jammed

Automatic 1.1m Cotton Fibre Opening Machine For Wadding Making

Structure of

Intergrated numerical control machining of bending frame work for stability

Even feeding by holding method

Strong magnet for sucking metal dusts

Structure of opening roller :rigid aluminium alloy carding plate or carding wire

Working width(mm) 1000-2000(customized)
capacity (kg/h) 100-500(can be decreased and increased)
feed roller Dia.(mm) 75
Rotation speed(r/min) 16
beater Dia.(mm) 420
Rotation speed(r/min) 900
installed power 6.95KW
dimensions 4500x1800x1000
net weight 0.8T

Automatic 1.1m Cotton Fibre Opening Machine For Wadding Making

Pre-Sales Service
*Inquiry and consulting support
*Sample testing support
*View our factory


After-Sales Service
*Training how to install the machine , training how to use the machine
*Engineers available to service machinery overseas
*Warranty :12 months

Automatic 1.1m Cotton Fibre Opening Machine For Wadding Making

Automatic 1.1m Cotton Fibre Opening Machine For Wadding Making
*Certificate :

Automatic 1.1m Cotton Fibre Opening Machine For Wadding Making
Trade information
*Payment terms: 30%deposite by TT, 70% as balance paid before delivery.
*Delivrey time: Appox 120 working days after receiving the advance payment
*Package: nake, wooden case
*Warrantty:12 months
*After sales service: we will send 2-3 workers to do the installation and commissioning
of the line at the request of the buyer. and the buyer should provide round-trip air plane
tickets, accommodation and allowance, the allowance is 170USD /person/day
*HS code :84490090
*MOQ: 1set

Company Information:

We are HongYi Nonwoven Machinery CO.LTD. , more than 10 years in china,about 100 workers ,5000m2 workshop
Occupied more than 10% market share in Chinese nonwoven machinery market.
Until now, we have established 10 series 0f nonwoven machinery all over the country and also expand our business scope abroad, up to date, we have exported production line to Southeast Asia, Europe, South America and Austria, etc.
We are applying for the certificate of ISO 9001 and CE.
Below are the main kinds of our products, from which you may acquaint yourselves with some of items we handle:
1)wasted cloth recycled production line
2)felt production line
3)100% cotton fabric production line
4)nonwoven fabric productiobn line
5)geo production line
6)geo fabric
7)nonwoven fabric
8)soundproofing material
9)sold mattress
10)coir mattress
We are looking for agent all over the world ,pls. Contact me and discuss more
Email: rainbow@hongyiwf.cn
whatsapp:+8615262513303
wechat:+8615262513303

About us:

Automatic 1.1m Cotton Fibre Opening Machine For Wadding Making

We look forward to working with you and have a long term cooperation in the future!
