Specifications
Brand Name :
NNT
Model Number :
NZK2B
Certification :
CE
Place of Origin :
China
MOQ :
1 pcs
Payment Terms :
T/T
Supply Ability :
500pcs 7days
Delivery Time :
5-7days
Description
NNT NZK2B Series Vacuum Generators

High-performance, energy-efficient vacuum solutions for advanced automation systems with up to 93% reduced air consumption and superior suction performance.

Product Overview

The NNT NZK2B Series Vacuum Generators represent cutting-edge vacuum technology designed for modern industrial automation. Utilizing the Venturi principle, these compact units generate powerful vacuum suction from compressed air without any moving parts, ensuring reliable, maintenance-free operation.

Engineered for precision and energy efficiency, the NZK2B series delivers exceptional performance across diverse applications from electronics manufacturing to automotive assembly. With advanced features like intelligent energy-saving functions and noise reduction technology, these vacuum generators set new standards for operational efficiency in demanding industrial environments.

NNT NZK2B Series Vacuum Generator with 93% Air Consumption Reduction, 50% Increased Suction Flow, and 20 ms Response Time for High-Speed Automation

Key Features & Benefits

Energy Efficiency

Intelligent energy-saving function reduces air consumption by up to 93% when target vacuum is reached, significantly lowering operational costs.


Enhanced Performance

Delivers 50% increased suction flow compared to single-stage vacuum generators through optimized nozzle design.


Noise Reduction

High-performance silencers lower operational noise while simultaneously improving suction flow characteristics.


Compact Design

Space-saving configuration ideal for integration into robotic end effectors and automated systems with limited installation space.


Durable Construction

Stainless steel valve cores and PTFE seals ensure longevity and reliability in challenging industrial environments.


Rapid Response

Quick vacuum generation reaching -60kPa in approximately 1.5 seconds at 0.5MPa supply pressure for high-speed operations.

Technical Specifications
Model Series Nozzle Diameter (mm) Max. Suction Flow [L/min(ANR)] Air Consumption [L/min(ANR)] Applicable Pad Sizes (mm) Key Features
NZK2□07 0.7 29 24 2～40 Compact design, Energy saving
NZK2□10 1.0 44 40 2～50 Balanced flow and consumption
NZK2□12 1.2 61 58 2～125 High suction for medium loads
NZK2□15 1.5 67 90 2～150 Maximum power for larger components
Application Examples

Electronics Manufacturing

Precision handling of delicate components like IC chips, PCB boards, and surface-mount devices with positional accuracy within ±0.05mm.


Automotive Assembly

Safe manipulation of body panels, trim components, glass pieces, and interior elements without surface damage.


Packaging Operations

Secure gripping of flexible packaging materials, pouches, and containers during filling, sealing, and palletizing processes.


Pharmaceutical Handling

Contamination-free transfer of vials, ampoules, and medical devices in compliance with GMP standards.

Comparative Advantages
Energy Savings
  • 90-93% lower energy consumption than continuous vacuum pumps
  • 70% reduced energy costs compared to traditional vacuum systems
  • Intelligent air-saving function for partial load operations
  • Optimized nozzle design minimizes compressed air requirements
Operational Benefits
  • Maintenance-free operation with no moving parts
  • Immediate vacuum availability without warm-up time
  • Quieter operation through advanced silencer technology
  • Compact size for easy integration into automated systems
  • Durable construction for long service life
