NNT NPF3W Precision Integrated Digital Flow Sensor Valve with ±0.5% F.S. Accuracy, 15 ms Response Time, and -0.1 to 1.0 MPa Operating Range for Industrial Automation
NNT NPF3W Precision Integrated Digital Flow Sensor Valve with ±0.5% F.S. Accuracy, 15 ms Response Time, and -0.1 to 1.0 MPa Operating Range for Industrial Automation
NNT NPF3W Precision Integrated Digital Flow Sensor Valve with ±0.5% F.S. Accuracy, 15 ms Response Time, and -0.1 to 1.0 MPa Operating Range for Industrial Automation
NNT NPF3W Precision Integrated Digital Flow Sensor Valve with ±0.5% F.S. Accuracy, 15 ms Response Time, and -0.1 to 1.0 MPa Operating Range for Industrial Automation
NNT NPF3W Precision Integrated Digital Flow Sensor Valve with ±0.5% F.S. Accuracy, 15 ms Response Time, and -0.1 to 1.0 MPa Operating Range for Industrial Automation
NNT NPF3W Precision Integrated Digital Flow Sensor Valve with ±0.5% F.S. Accuracy, 15 ms Response Time, and -0.1 to 1.0 MPa Operating Range for Industrial Automation
Specifications
MOQ :
1pcs
Payment Terms :
T/T
Supply Ability :
500 pcs within 7 working days
Delivery Time :
5-7 work days
Brand Name :
NNT
Model Number :
NPF3W※
Certification :
CE
Place of Origin :
China
Description
NNT NPF3W※ Precision Flow Control Valve
Advanced flow control solutions offering superior accuracy, durability, and performance for industrial automation applications with ±0.5% F.S. accuracy, 15 ms response time, and -0.1 to 1.0 MPa operating range.
Product Overview
The NPF3W series represents the next generation of precision flow control valves, designed for demanding industrial environments. Engineered with advanced materials and innovative design principles, these valves provide consistent performance in various industrial applications.
With a focus on precision engineering, the NPF3W series incorporates features that minimize pressure drop while maintaining accurate flow control, ensuring optimal system performance and energy efficiency.
  • High precision flow control with minimal deviation
  • Robust construction for extended service life
  • Wide operating pressure and temperature range
  • Easy installation and maintenance procedures
  • Compatible with various industrial media

NNT NPF3W Precision Integrated Digital Flow Sensor Valve with ±0.5% F.S. Accuracy, 15 ms Response Time, and -0.1 to 1.0 MPa Operating Range for Industrial Automation

NNT NPF3W Precision Integrated Digital Flow Sensor Valve with ±0.5% F.S. Accuracy, 15 ms Response Time, and -0.1 to 1.0 MPa Operating Range for Industrial AutomationNNT NPF3W Precision Integrated Digital Flow Sensor Valve with ±0.5% F.S. Accuracy, 15 ms Response Time, and -0.1 to 1.0 MPa Operating Range for Industrial AutomationNNT NPF3W Precision Integrated Digital Flow Sensor Valve with ±0.5% F.S. Accuracy, 15 ms Response Time, and -0.1 to 1.0 MPa Operating Range for Industrial Automation

Key Features & Benefits
NNT NPF3W Precision Integrated Digital Flow Sensor Valve with ±0.5% F.S. Accuracy, 15 ms Response Time, and -0.1 to 1.0 MPa Operating Range for Industrial Automation
High Precision Control
Advanced design ensures precise flow regulation with minimal fluctuation, providing consistent performance for sensitive applications.
NNT NPF3W Precision Integrated Digital Flow Sensor Valve with ±0.5% F.S. Accuracy, 15 ms Response Time, and -0.1 to 1.0 MPa Operating Range for Industrial Automation
Robust Construction
Manufactured with high-grade materials and protective coatings to withstand harsh industrial environments and extend product lifespan.
NNT NPF3W Precision Integrated Digital Flow Sensor Valve with ±0.5% F.S. Accuracy, 15 ms Response Time, and -0.1 to 1.0 MPa Operating Range for Industrial Automation
Easy Integration
Designed for simple installation and compatibility with existing industrial systems, reducing downtime and implementation costs.
NNT NPF3W Precision Integrated Digital Flow Sensor Valve with ±0.5% F.S. Accuracy, 15 ms Response Time, and -0.1 to 1.0 MPa Operating Range for Industrial Automation
Energy Efficient
Optimized flow paths and precision control mechanisms minimize energy consumption while maintaining performance standards.
Technical Specifications
Model Series NPF3W-10 NPF3W-15 NPF3W-20 NPF3W-25
Port Size 1/8" 1/4" 3/8" 1/2"
Max Operating Pressure 1.0 MPa 1.0 MPa 1.0 MPa 1.0 MPa
Flow Range 0.05 - 30 L/min 0.1 - 70 L/min 0.2 - 150 L/min 0.3 - 250 L/min
Operating Temperature -5°C to 60°C -5°C to 60°C -5°C to 60°C -5°C to 60°C
Body Material Stainless Steel Stainless Steel Stainless Steel Stainless Steel
Seal Material FKM FKM FKM FKM
Weight 0.15 kg 0.25 kg 0.45 kg 0.65 kg
Industry Applications
Industrial Automation
Precise control of pneumatic circuits in automated manufacturing and assembly lines.
Semiconductor Manufacturing
Accurate flow control for cleanroom environments and sensitive production processes.
Packaging Machinery
Consistent flow regulation for packaging systems requiring precise pneumatic control.
Medical Equipment
Reliable flow control in diagnostic and therapeutic medical devices.
