NNT PF2A7※※H Digital Flow Switch and Flow Monitor with 12000 L/min Max. Flow, ±1.5% F.S. Accuracy, and 1 s Response Time for Industrial Automation
NNT PF2A7※※H Digital Flow Switch and Flow Monitor with 12000 L/min Max. Flow, ±1.5% F.S. Accuracy, and 1 s Response Time for Industrial Automation
NNT PF2A7※※H Digital Flow Switch and Flow Monitor with 12000 L/min Max. Flow, ±1.5% F.S. Accuracy, and 1 s Response Time for Industrial Automation
NNT PF2A7※※H Digital Flow Switch and Flow Monitor with 12000 L/min Max. Flow, ±1.5% F.S. Accuracy, and 1 s Response Time for Industrial Automation
NNT PF2A7※※H Digital Flow Switch and Flow Monitor with 12000 L/min Max. Flow, ±1.5% F.S. Accuracy, and 1 s Response Time for Industrial Automation
NNT PF2A7※※H Digital Flow Switch and Flow Monitor with 12000 L/min Max. Flow, ±1.5% F.S. Accuracy, and 1 s Response Time for Industrial Automation
NNT PF2A7※※H Digital Flow Switch and Flow Monitor with 12000 L/min Max. Flow, ±1.5% F.S. Accuracy, and 1 s Response Time for Industrial Automation
NNT PF2A7※※H Digital Flow Switch and Flow Monitor with 12000 L/min Max. Flow, ±1.5% F.S. Accuracy, and 1 s Response Time for Industrial Automation
Specifications
Brand Name :
NNT
Model Number :
NPF2A7※※H
Certification :
CE
Place of Origin :
China
MOQ :
1pcs
Payment Terms :
T/T
Supply Ability :
500 pcs within 7 working days
Delivery Time :
5-7 working days
Description
NNT NPF2A7※※H Series Digital Flow Switch

Professional-grade flow monitoring solution for precise and reliable air flow control in demanding industrial applications

NNT PF2A7※※H Digital Flow Switch and Flow Monitor with 12000 L/min Max. Flow, ±1.5% F.S. Accuracy, and 1 s Response Time for Industrial Automation

Product Overview

The NNT NPF2A7※※H Series is a high-performance digital flow switch designed for precise and reliable air flow monitoring in demanding industrial environments. Engineered with advanced digital technology, this series provides accurate flow measurement, flexible output options, and robust construction suitable for factory automation and process control applications.

High Accuracy Measurement

Delivers precise flow measurement with digital accuracy for consistent process control and monitoring.

Digital Technology

Incorporates advanced digital processing for reliable performance and flexible configuration options.

Industrial Durability

Built to withstand harsh industrial environments with robust construction and reliable operation.

Technical Specifications

Comprehensive technical details of the NPF2A7※※H Series for system integration and application planning

General Specifications
  • Measurement FluidDry air / Nitrogen
  • Fluid Temperature0 to 50°C
  • Port SizeRc1/8, Rc1/4
  • Protection RatingIP65
Performance Specifications
  • Set Flow Range10 to 300 L/min
  • Operating Pressure0.1 to 1.0 MPa
  • Accuracy±10% FS (20 to 300 L/min)
  • Repeatability±2% FS
Electrical Specifications
  • Power Supply12-24 VDC ±10%
  • Current Consumption40 mA max.
  • Output SignalsNPN/PNP open collector
  • Response Time1 sec max.
Environmental Specifications
  • Operating Temp.0 to 50°C
  • Storage Temp.-10 to 60°C
  • Ambient Humidity35 to 85% RH
  • Vibration Resistance10 to 55 Hz
Key Features & Benefits

Advanced capabilities designed to optimize your industrial flow monitoring applications

Dual Display Configuration

Available with integrated display or display-separated design for flexible installation in various industrial layouts and visibility requirements.

Flexible Setpoint Adjustment

Easy-to-configure setpoints with intuitive operation for precise flow control tailored to specific application requirements.

Robust IP65 Enclosure

High protection rating ensures reliable operation in demanding environments with dust and water exposure concerns.

Wide Voltage Range

12-24 VDC power supply compatibility allows for flexible integration with various industrial control systems.

Dual Output Options

NPN and PNP output configurations provide compatibility with different PLC systems and control architectures.

Fast Response Time

Maximum 1-second response ensures timely detection of flow changes for critical process monitoring applications.

Industrial Applications

The NPF2A7※※H Series is engineered for diverse industrial automation and process control applications

Factory Automation

Monitor air flow in pneumatic systems, robotics, and automated assembly lines for consistent operation.

Process Control

Ensure precise flow rates in manufacturing processes requiring controlled air supply and distribution.

Air Supply Monitoring

Monitor compressor output and distribution systems to prevent downtime and ensure equipment protection.

Laboratory Equipment

Control and monitor air flow in analytical instruments and testing equipment requiring precise flow rates.
