Specifications
Brand Name :
UND
Place of Origin :
Shaanxi, China
Application :
anti-drone
Feature :
Durable
Type :
security protection products
Working frequency band :
C band
Main detection target :
UAV Drone
Azimuth coverage :
360°
Detection range :
1.5km for drone
MOQ :
1
Price :
$43,800-49,500
Description

2 KM UAV /Drone Detection Radar

360º rotating radar turntable radar

Product Overview:

The LAS-20X, it is an advanced micro/small civilian unmanned aerial vehicle detection system, suitable for security protection in key areas such as prisons, exhibitions, and bases.

It consists of three main parts: a radar array, a mechanical turntable, and a power adapter.

The radar array is the core of the system, responsible for detecting and tracking unmanned aircraft;

The mechanical turntable ensures the flexible rotation of the radar, enabling all-round monitoring.

The power adapter provides stable power supply, ensuring the continuous operation of the system.

This system can obtain real-time flight information such as the position, distance, altitude, and speed of the unmanned aircraft, providing accurate data for alerting and target indication, effectively ensuring the security of key areas. It can accurately provide the position, distance, altitude, and speed of the target.

Product features:

Ø High real-time and high precision: Real-time tracking, high target accuracy, continuous trajectory;

Ø Strong environmental adaptability: Capable of working 24/7, adapting to harsh environments such as night, rain, snow, haze, and dust;

Ø High flexibility: Long-distance target detection, easy to set up;

Ø DBF technology: DBF technology transmits multi-beam technology to improve anti-interference ability;

Products parameter:

Parameter

LAS-20X

Working system

Phased array system (azimuth scanning + pitch scanning) pulse Doppler

Working frequency

X Band

Effective detection Range

100m~2km (UAV; Drone)

Directional coverage

360°

Detection velocity

1.8km/h~108km/h

Data rate

≥0.2Hz

Data interface

RJ45/1 channel 100 Gigabit Ethernet

Power input

≤100W (Power consumption)
Input voltage: AC200-AC240

Working Temperature

-40℃~+55℃

Weight

≤30 kg

ABOUT US

UND-LAS-20X X Band 2 km Anti-drone Uav Detection radar Low-altitude Monitoring radar

UND-LAS-20X X Band 2 km Anti-drone Uav Detection radar Low-altitude Monitoring radar

UND-LAS-20X X Band 2 km Anti-drone Uav Detection radar Low-altitude Monitoring radarUND-LAS-20X X Band 2 km Anti-drone Uav Detection radar Low-altitude Monitoring radar

Certification

UND-LAS-20X X Band 2 km Anti-drone Uav Detection radar Low-altitude Monitoring radarUND-LAS-20X X Band 2 km Anti-drone Uav Detection radar Low-altitude Monitoring radar

Why Choose Us?

OEM/ODM capabilities

Competitive pricing & bulk discounts

Fast shipping & customs clearance support

Turnkey project solutions

FAQ

Q: What’s the lead time for orders?

A: Standard models ship in 15–30 days; customized units require 30–45 days.

Q: Do you provide after-sales service overseas?

A: Yes, we have partnered service centers in key regions.

Q: Can I request a customized bucket size?

A: Absolutely! We offer tailored attachments.

Q: What documents do you provide for export?

A: Full export package (Commercial Invoice, Packing List, Bill of Lading, COC, etc.).

Q: How do I place an order?

A: Contact us via email/phone for a quote, then confirm with a PO.
