Thermal Imaging Night Vision Binocular IP65 640×480 Resolution
Thermal Imaging Night Vision Binocular IP65 640×480 Resolution
Specifications
MOQ :
1
Price :
100-50000（CNY）
Packaging Details :
Carton
Delivery Time :
Spot goods: 3-7 days Customized/imported products: 15-60 days
Payment Terms :
T/T
Supply Ability :
In stock
Price Term :
EXW price
Special Features :
thermal camera
Advance :
Compact, light
Pan :
360 degree auto tracking
Country of Origin :
China
Brand :
EV
Place of Origin :
CHINA
Brand Name :
EV
Description
Thermal Imaging Night Vision Binocular IP65 640×480 Resolution
Functional Thermal Imaging Binocular with IP65 rating and 640×480 resolution for superior thermal detection capabilities.
Key Features
  • High-Resolution Thermal Imaging - Advanced infrared sensor with 384×288 or 640×480 resolution for crisp thermal detection. Detects heat signatures in total darkness, fog, smoke, and light foliage.
  • OLED Display Technology - High-contrast, low-latency OLED screen for sharp, real-time thermal imaging. Energy-efficient with wide viewing angles for optimal visibility.
  • Long Detection Range - Identifies human-sized targets at extended ranges (800m-1.5km+ depending on model). Adjustable digital zoom for precise target observation.
  • Multiple Color Palettes & Imaging Modes - White Hot, Black Hot, Rainbow, and other color modes for different environments. Picture-in-Picture (PiP) or edge enhancement for improved target recognition.
RM-35 Infrared Thermal Sight Specifications
Image sensor Polysilicon uncooled focal plane array
Lens 35mm hard-coated germanium lens germanium metal manual focus lens, coated with hard carbon and anti-reflective coating
Magnification 2.6 times
Digital zoom 5.2-10.4 times
Diopter -4~+2
Viewing angle (HXV) 10.4x8.0
Exit pupil distance 52mm
Exit pupil diameter 6mm
Wavelength range 7~14um
Detection element 384*288
OLED OLED, 800X600
Thermal sensitivity ≦50mk (@25℃)
Detection distance >1000m, people (1.8m*0.5m) >1500m objects (2.3m*2.3m)
Recognition distance >250m, people (1.8m*0.5m) >400 m objects (2.3 m *2.3 m)
Battery specifications 4 3V rechargeable lithium batteries
Working hours 8 hours
Frame rate 50HZ
Non-uniform correction using no-baffle technology
Image polarity black hot/white hot/brown/iron red/green
Operating temperature -40℃～+50℃
Storage temperature -45℃～+85℃
Size 205mm*74mm*66mm
Colour Black
Weight 0.66kg
Protection level IP65
Video output Yes
External power supply Yes
