Nickel Alloy Inconel 718 Spring Wire
Nickel Alloy Inconel 718 Spring Wire
Specifications
Brand Name :
HUONA
Model Number :
Inconel 718
Certification :
ISO9001
Place of Origin :
CHINA
MOQ :
10
Price :
DISCUSS
Payment Terms :
L/C,T/T,Western Union,
Supply Ability :
1000kg Per Week
Delivery Time :
7-21 DAYS
Packaging Details :
Spool+Carton Box
Applications :
Precision instruments, optical and laser components, aerospace and defense industry
Corrosion Resistance :
Excellent
Electrical Resistivity :
80 μΩ·cm
Tensile Strength :
500 MPa
Spray Process :
Flame, Arc, Plasma
Commerical Grade Name :
Elgiloy Alloy
Diameter :
0.02 mm – 3.0 mm
Standard :
AISI, BS, JIS, ASTM, DIN, GB
Thickness :
0.02-2.5mm
Chemical Composition :
Mg，Al，Zn
Specification :
RoHS, SGS
Manufacturing Process :
Cold-Rolled
Product Type :
Wire
Spec :
ASTM B166
Description
Nickel Alloy Inconel 718 Spring Wire
Product Attributes
Attribute Value
Applications Precision instruments, optical and laser components, aerospace and defense industry
Corrosion Resistance Excellent
Electrical Resistivity 80 μΩ·cm
Tensile Strength 500 MPa
Spray Process Flame, Arc, Plasma
Commerical Grade Name Elgiloy Alloy
Diameter 0.02 mm – 3.0 mm
Standard AISI, BS, JIS, ASTM, DIN, GB
Thickness 0.02-2.5mm
Chemical Composition Mg，Al，Zn
Specification RoHS, SGS
Manufacturing Process Cold-Rolled
Product Type Wire
Spec ASTM B166
Product Description

Inconel is a family of austenitic nickel chromium based super alloys.

Inconel 718 is a nickel-chromium-molybdenum alloy designed to resist a wide range of severely corrosive environments, pitting and crevice corrosion. This nickel steel alloy also displays exceptionally high yield, tensile, and creep-rupture properties at high temperatures. This nickel alloy is used from cryogenic temperatures up to long term service at 1200° F.

This superalloy is used in a variety of industries such as aerospace, chemical processing, marine engineering, pollution-control equipment, and nuclear reactors.

Application Field

High temperature components, such as turbine blades, guide vanes, turbine disks, high pressure compressor disks, machine manufacturing and combustion chambers used in the manufacture of aviation, naval and industrial gas turbines.

Chemical Composition Comparison
Item Inconel 600 Inconel 601 Inconel 617 Inconel 625 Inconel 690 Inconel 718 Inconel X750 Inconel 825
C ≤0.15 ≤0.1 0.05-0.15 ≤0.08 ≤0.05 ≤0.08 ≤0.08 ≤0.05
Mn ≤1 ≤1.5 ≤0.5 ≤0.35 ≤0.5 ≤0.35 ≤1 ≤1
Fe 6~10 rest ≤3 rest 7~11 rest 5~9 ≥22
P ≤0.015 ≤0.02 ≤0.015 -- -- -- -- --
S ≤0.015 ≤0.015 ≤0.015 ≤0.015 ≤0.015 ≤0.01 ≤0.01 ≤0.03
Si ≤0.5 ≤0.5 ≤0.5 ≤0.35 ≤0.5 ≤0.35 ≤0.5 ≤0.5
Cu ≤0.5 ≤1 -- ≤0.3 ≤0.5 ≤0.3 ≤0.5 1.5-3
Ni ≥7.2 58-63 ≥44.5 50-55 ≥58 50-55 ≥70 38-46
Co -- -- 10~15 ≤10 -- ≤1 ≤1 --
Al -- 1-1.7 0.8-1.5 ≤0.8 -- 0.2-0.8 0.4-1 ≤0.2
Ti -- -- ≤0.6 ≤1.15 -- -- 2.25-2.75 0.6-1.2
Cr 14-17 21-25 20-24 17-21 27-31 17-21 14-17 19.5-23.5
Nb+Ta -- -- -- 4.75-5.5 -- 4.75-5.5 0.7-1.2 --
Mo -- -- 8~10 2.8-3.3 -- 2.8-3.3 -- 2.5-3.5
B -- -- ≤0.006 -- -- -- -- --
