4.0mm Thickness 4j42 /Nilo42/ Uniseal alloy 42 strip Cold Rolled
4.0mm Thickness 4j42 /Nilo42/ Uniseal alloy 42 strip Cold Rolled
4.0mm Thickness 4j42 /Nilo42/ Uniseal alloy 42 strip Cold Rolled
4.0mm Thickness 4j42 /Nilo42/ Uniseal alloy 42 strip Cold Rolled
4.0mm Thickness 4j42 /Nilo42/ Uniseal alloy 42 strip Cold Rolled
4.0mm Thickness 4j42 /Nilo42/ Uniseal alloy 42 strip Cold Rolled
4.0mm Thickness 4j42 /Nilo42/ Uniseal alloy 42 strip Cold Rolled
4.0mm Thickness 4j42 /Nilo42/ Uniseal alloy 42 strip Cold Rolled
4.0mm Thickness 4j42 /Nilo42/ Uniseal alloy 42 strip Cold Rolled
4.0mm Thickness 4j42 /Nilo42/ Uniseal alloy 42 strip Cold Rolled
Specifications
Brand Name :
HUONA
Model Number :
4j42 /Nilo42
Certification :
ISO9001
Place of Origin :
CHINA
MOQ :
50-100 kgs per each size
Price :
Bargain
Payment Terms :
L/C,Western Union,T/T,MoneyGram
Supply Ability :
10000 Tons/Year
Delivery Time :
5-21days
Packaging Details :
Cartons/WoodBox
Model NO. :
4J42 sealing Alloy Strip
Specification :
Base on customers′ request
Grade :
4J42
Size :
Strip---Thickness 0.1mm~4.0mm, width:≤300mm
Condition :
cold rolled(hot), bright, bright annealed
MOQ :
50-100 kgs per each size
Description

Basic Info.

Model NO.
4J42 sealing Alloy Strip
Certificate
ISO 9001&RoHS&BV
Model No.
4j42 /Nilo42/ Uniseal 42
Transport Package
According to Customer′ S Requirements
Specification
Base on customers′ request
Trademark
HUONA
Origin
Shanghai
HS Code
7505220000
Production Capacity
10000 Tons/Year

Product Description

High Quality 4j42 /Nilo42/ Uniseal 42 Sealing Alloy Strip
1.Description:


Grade and chemical composition

Grade
Mass fraction (%)

C
P
S
Mn
Si
B
Al
C0
Ni
Cr
Fe

≤

4J42
0.05
0.020
0.020
0.80
0.30

0.10
1.0
41.5~42.5

balance



tensile strength for strips

status
tensile strength /MPa

soft
<590

hard
>820










hardness of strip in deep punching status

deep punching
thickness/mm
Hardness HV

Fe-Ni-Cr

≤190

Fe-Ni
>2.5
≤190

≤2.5
≤165





heat treating regime and coefficient of linear expansion

Grade
Heat treatment on samples
a/(10-6/K)

20-300°C
20~400%
20-450°C

4J42
Heat the sample to (900±20)°C in hydrogen atmosphere, keep the temperature for one hour, cool to below 200°C at the speed ≤5°C/min then discharge
4.0~5.0

6.5~7.5

6.5~7.2
6.5~7.2


9.2~10.0
9.2~9.9






coefficient of expansion

Grade
Average coefficient of expansion a/(10-6/K)

20~100°C
20~200°C
20~300°C
20~400°C
20~450°C
20~500°C
20~600°C

4J42
5.6
4.9
4.8
5.9
6.9
7.8
9.2





2.Size
Strip---Thickness 0.1mm~4.0mm, width:≤300mm,Condition: cold rolled(hot), bright, bright annealed


3.Usage
It is applied to soft glass-to-metal and ceramic-to-metal seals in electronic component.




4.MOQ
50-100 kgs per each size; If we have in stock, 1kgs is available for us.


5. Payment
T/T, 30% deposit and the balance paid against the B/L copy.
100% L/C at sight;
Wesetern Union;
Paypal;

6.Shippment
By Sea;
By Air (DHL,TNT,UPS,FEDEX etc)


7.Application
Petrochemical Industry; Pulp and paper Industry; Aerospace Industry;
Industrial Furnace; Special Welding; Heating Treatment Industry;
Nuclear Power Industry; Marine Industry; Shipbuilding Industry;


8.Packing
Standard export packing, carton with plywood case for safety
Strip: Packed in Nylon Polybag first
The goods can be packed as the clients demand.



9.Delivery time
We can do the order 45-50days upon receive the 30% deposit or L/C document.



10.Advantages
1.Pass:ISO9001 certification
2.fine after-sale services
3.small order accepted

11.Delivery conditions and finishes



Strip:bright surface; special requirements made as the clients
