Specifications
AWS Standard :
AWS A5.14 ERNiFeCr-2
Payment Terms :
T/T
Melting Point :
1260-1336°C
Model Number :
ERNiFeCr-2
MOQ :
10 Kilograms
Tensile Strength :
≥ 1240 MPa
Material Grade :
ERNiFeCr-2 / Inconel 718 / GH4169
Delivery Time :
3 working days for stock, 10-20 days for production
Packaging Details :
1KG / 5KG / 15KG plastic spool with vacuum-sealed packaging, export-grade corrugated carton
Welding Process :
TIG (GTAW), MIG (GMAW)
Brand Name :
Custom
Price :
negotiation
AMS Standard :
AMS 5832
Supply Ability :
20000 Kilograms per Month
Certification :
ISO 9001:2015
Place of Origin :
Shanghai, China
Diameter Range :
customize
Description
ERNiFeCr-2 Inconel 718 Nickel Alloy TIG Welding Wire AWS A5.14 AMS 5832 for Aerospace Turbine Repair
ERNiFeCr-2 Inconel 718 (GH4169) Nickel Alloy TIG Welding Wire

We supply premium ERNiFeCr-2 nickel alloy welding wire fully compliant with AWS A5.14 and AMS 5832 standards. Designed for TIG (GTAW) welding of Inconel 718 and similar nickel-chromium superalloys, our wire delivers excellent arc stability, minimal spatter, and X-ray quality welds for critical aerospace and industrial applications.

Chemical Composition
Element Percentage
Ni 50.0-55.0
Cr 17.0-21.0
Fe Bal
Nb 4.75-5.5
Mo 2.8-3.3
Technical Specifications
Parameter Specification
Max Continuous Operating Temperature (°C) 650
Resistivity (Ω/cmf, 20°C) 1.25
Density (g/m³) 8.19-8.24
Thermal Conductivity (KJ/m·h·°C) 40.3
Tensile Strength (N/mm²) 1240
Melting Point (°C) 1260-1320
Hardness (Hv) 350-450
Elongation (%) ≥12
Product Features
  • AWS A5.14 ERNiFeCr-2 Classification: Exact chemistry match for Inconel 718 base metal, ensuring weld deposits retain the same high-temperature strength and corrosion resistance as the parent material.
  • Precision Layer Wound Spooling: Diamond-precision layer wound for smooth, uninterrupted wire feeding with zero tangling or bird-nesting.
  • Vacuum-Sealed Packaging: Each spool is vacuum-packed with desiccant to prevent moisture absorption and oxidation during storage and shipping.
  • Clean Weld Deposit: Low impurity levels (S, P, O, N) guarantee clean, crack-free weld beads suitable for radiographic inspection.
  • Mill Test Certificate (MTC): Full chemical and mechanical traceability per EN 10204 3.1 included with every shipment.
Typical Applications
  • Aerospace: Repair and fabrication of turbine discs, compressor blades, and combustion chambers
  • Oil & Gas: Welding of downhole tools, valve bodies, and wellhead equipment in sour service environments
  • Power Generation: Gas turbine hot-section component repair and overlay welding
  • Nuclear: Reactor internals and structural component welding
  • General Industry: Joining Inconel 718 to dissimilar alloys for high-temperature applications
Why Choose Us
  • 20+ years specializing in nickel alloy welding consumables
  • In-house spectrometer and mechanical testing for every batch
  • Flexible spool sizes: from 1KG trial orders to container loads
  • Fast global delivery via DHL, FedEx, air freight, or sea freight
ERNiFeCr-2 Inconel 718 Nickel Alloy TIG Welding Wire AWS A5.14 AMS 5832 for Aerospace Turbine Repair ERNiFeCr-2 Inconel 718 Nickel Alloy TIG Welding Wire AWS A5.14 AMS 5832 for Aerospace Turbine Repair ERNiFeCr-2 Inconel 718 Nickel Alloy TIG Welding Wire AWS A5.14 AMS 5832 for Aerospace Turbine Repair
Contact us today for a tailored quote or technical datasheet. Our welding engineering team is available to support your application requirements.
